Partiron

Suzuki GN250 (1983) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP, THROTTLE

57110-45000

$41.63

2

SWITCH ASSY, HANDLE RH | Includes Item(s) 3 This part replaces 37200-49470.

37200-49471

Unavailable

3

SCREW This part replaces 37591-49210.

09125-05102

$1.61

4

LEVER ASSY, BRAKE | Includes Item(s) 5 - 11

57300-11900

Unavailable

5

LEVER, BRAKE

57420-26400

Unavailable

6

BOLT This part replaces 57431-11011.

57431-11013

$6.31

7

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

8

BOLT

57451-49100

Unavailable

9

ADJUSTER, CABLE

57441-44400

$6.28

10

NUT This part replaces 57442-44400.

57442-11010

$2.79

11

SWITCH ASSY, STOP This part replaces 57470-10400.

57460-10400

$37.53

12

COVER, BRAKE LEVER

57341-28000

$13.05

13

BOOT, CLUTCH CABLE This part replaces 58273-31000.

58273-31001

$2.22

14

BAND

09407-12402

$3.04
