Honda GL1800CAC (15) MOTORCYCLE, JPN, VIN# JH2SC680-FK100001 STEP Diagram

#

Description
Price

1

SPRING, KICK STARTER STOPPER

28333-300-000

$2.80

2

ARM, R. STEP (COO)

50612-MCA-305

$18.61

3

BRACKET, R. MAIN STEP *NHA86M* (MAT BALLISTIC BLACK)

50613-MCA-S40ZC

$30.16

4

BRACKET, L. MAIN STEP *NHA86M* (MAT BALLISTIC BLACK)

50614-MCA-S40ZC

$34.97

5

SPRING, R. STEP RETURN

50617-MM5-000

$4.58

6

PLATE, STEP SETTING

50619-MCA-000

$6.87

7

PLATE, STEP SETTING

50619-MT3-000

$11.03

8

PIN, STEP BAR

50639-ML0-010

$4.84

9

ARM, L. STEP (COO)

50642-MCA-305

$18.61

10

SPRING, L. STEP RETURN

50644-MM5-000

$4.58

11

RUBBER, MAIN STEP (COO)

50661-MCA-305

$13.99

12

RUBBER, STEP (COO)

50661-MT3-305

$6.91

13

BAR, R. PILLION STEP (COO)

50711-MT3-305

$54.18

14

BAR, L. PILLION STEP (COO)

50712-MT3-305

$50.75

15

HOLDER, R. PILLION STEP *NHA86M* (MAT BALLISTIC BLACK)

50715-MJG-670ZB

$32.78

16

PLATE, PILLION STEP CLICK

50718-MT3-000

$4.29

17

HOLDER, L. PILLION STEP *NHA86M* (MAT BALLISTIC BLACK)

50815-MJG-670ZB

$35.00

18

COLLAR, STEP (LOWER)

51486-MFJ-D00

$3.50

19

BOLT, SOCKET (8X22)

90100-GCT-J50

$1.79

20

BOLT, MAIN STEP RUBBER SETTING

90115-MT3-000

$2.50

21

BOLT, SOCKET (8X32)

90155-MBL-610

$4.67

22

BOLT, CAP (6X25)

92501-06025-0A

$2.68

23

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

Unavailable

23

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

Unavailable

23

WASHER, PLAIN (6MM) (USED ON TAILLIGHT)

94101-06800

Unavailable

24

WASHER, PLAIN (8MM)

94101-08000

Unavailable

25

PIN, COTTER (1.6X12)

94201-16120

$1.04

26

PIN, COTTER (2.0X15)

94201-20150

$1.04

27

PIN C, PILLION FOOTPEG

95015-83000

$2.22

28

BALL, STEEL (#8) (1/4)

96211-08000

Unavailable
