Description

Price

1

PLATE, DIAPHRAGM

22887-MGE-006

$7.29

2

DIAPHRAGM

22888-MGE-006

$11.39

3

CAP, MASTER CYLINDER

22889-MGE-006

$31.54

4

SWITCH ASSY., FR. STOP

35340-MGS-D31

$16.99

5

HOSE A, FR. BRAKE

45123-MKC-A01

$57.88

6

CLAMP A, FR. BRAKE

45155-MKC-A00

$6.49

7

BOOT

45504-410-003

$11.17

8

MASTER CYLINDER SUB-ASSY., FR. BRAKE

45510-MKC-A01

$239.43

9

PROTECTOR

45512-MA6-006

$4.09

10

HOLDER, MASTER CYLINDER

45517-MAM-A62

$13.11

11

MASTER CYLINDER SET

45530-MA5-671

$65.84

12

CAP, BRAKE MASTER CYLINDER HOLDER

45553-MAM-A60

$2.97

13

LEVER ASSY., R. HANDLE

53170-MKC-A11

$55.46

14

BOLT, FLANGE (6X12) (L. SIDE ONLY)

90013-GHB-610

$2.15

15

BOLT, SOCKET (6X22)

90101-MCL-000

$1.34

16

BOLT, FLANGE (6MM)

90111-187-000

$6.94

17

BOLT, HANDLE LEVER

90114-MG9-951

$7.53

18

BOLT, OIL (10X22) (SAGA)

90145-MS9-612

$6.99

19

NUT, CAP (6MM)

90202-ZV0-000

$2.69

20

WASHER, OIL BOLT

90545-300-000

$6.56

21

CIRCLIP

90651-MA5-671

$2.38

22

SCREW, FLAT (4X12)

93600-04012-0G

$0.84

22

SCREW, FLAT (4X12) This part replaces 93600-04012-1G.
