Honda GL1800BAC (17) GOLDWING F6B, JPN, VIN# JH2SC681-HK400001 ENGINE GUARD Diagram

#

Description
Price

1

RUBBER, TENSIONER ARM

61112-727-000

$2.90

2

GUARD, R. ENGINE

62501-MJG-670

$247.54

3

GUARD, L. ENGINE

62601-MJG-670

$247.54

4

GROMMET, RR. COVER

83504-GE0-000

$2.80

5

COVER, R. ENGINE SIDE

83511-MCA-S40

$132.00

6

STAY, R. ENGINE SIDE COVER

83512-MCA-A00

$7.68

7

MAT, R. ENGINE SIDE COVER

83514-MCA-S40

$18.35

8

GROMMET, AIR CLEANER HOUSING

83551-300-000

$3.42

9

GROMMET, AIR CLEANER HOUSING

83551-GE2-000

Unavailable

10

COVER, L. ENGINE SIDE

83561-MCA-S40

$155.77

11

MAT, L. ENGINE SIDE COVER

83564-MCA-640

$14.71

12

GROMMET A, SIDE COVER

83601-MB0-000

$4.20

13

STAY, SADDLEBAG

84100-MJG-670

$1,181.36

14

RUBBER, SADDLEBAG MOUNTING

84128-MCA-000

$3.32

15

PIPE, R. SADDLEBAG GUARD

84130-MJG-670

$96.22

16

PIPE, L. SADDLEBAG GUARD

84140-MJG-670

$96.22

17

PIPE, RR. FRAME END

84201-MCA-S40

$38.96

18

NUT, FLANGE (8MM)

94050-08000

$0.86

19

BOLT, FLANGE (6X12)

96300-06012-07

$1.17

20

BOLT, FLANGE (8X25)

96300-08025-00

$1.48

21

BOLT, FLANGE (8X20)

96300-08020-00

$1.43

21

BOLT, FLANGE (8X20) This part replaces 96400-08020-00.

96300-08020-00

$1.43

22

BOLT, FLANGE (8X40)

96400-08040-00

$1.84

23

BOLT, FLANGE (8X45)

96400-08045-00

$2.04
