Honda GL1800A (04) GOLD WING, USA, VIN# 1HFSC470-4A300001 REAR SHOCK ABSORBER Diagram

#

Description
Price

1

CLIP, THROTTLE WIRE

17938-SE0-941

$6.80

2

CUSHION ASSY., RR.

52400-MCA-003

Unavailable

3

COLLAR, CONNECTING ROD PIVOT

52462-MCA-000

$16.43

4

COLLAR A, CUSHION ARM

52463-MAW-760

$9.59

5

COLLAR C, CUSHION ARM

52463-MCA-000

$12.05

6

ARM SUB-ASSY., CUSHION

52465-MCA-000

$300.89

7

COLLAR C, CUSHION ARM

52465-MY1-000

$5.90

8

ROD SUB-ASSY., CUSHION CONNECTING

52475-MCA-000

$126.34

9

GROMMET, MOTOR MOUNTING

52491-MCA-000

$4.83

10

STAY, MOTOR

52492-MCA-000

$3.69

11

LABEL, RR. DAMPER (ENGLISH)

87516-KV6-610

$4.93

12

BOLT, SOCKET (12X90)

90110-MCA-000

$12.44

13

BOLT, SOCKET (10X55)

90110-ML7-000

$5.43

14

BOLT, SOCKET (12X127)

90111-MCA-000

$13.97

15

BOLT, FLANGE (12X99)

90123-MCA-000

$5.36

16

BOLT, FLANGE (10X55)

90153-KF0-000

$9.92

17

NUT, U (10MM) (FUSE RASHI)

90304-GE8-003

$3.67

18

NUT, FLANGE (12MM) (FUSERASHI)

90306-KF0-003

$3.85

19

BEARING, NEEDLE (17X24X17) (KOYO)

91071-MY1-005

$19.69

20

BEARING, NEEDLE (20X26X20)

91072-MY1-005

$18.51

21

DUST SEAL (20X26X4.5) (ARAI)

91254-KS6-003

$9.19

22

DUST SEAL (17X24X5) (ARAI)

91262-KV3-831

$6.21

23

BOLT, FLANGE (6X12)

95701-06012-00

$1.62

24

BOLT, FLANGE (8X25)

95701-08025-00

$1.79
