Description

Price

1

PUMP ASSY., OIL

15110-MCA-000

$184.39

2

ROTOR (INNER)

15121-MG3-000

$20.31

3

ROTOR (OUTER)

15122-MG3-000

$31.31

4

SPROCKET, OIL PUMP DRIVEN (22T)

15134-MCA-000

$39.87

5

CHAIN, OIL PUMP (DID25H-54L) (54L) (DAIDO)

15135-MCA-003

$21.15

6

STRAINER, OIL

15153-MCA-000

$28.25

7

GASKET, OIL STRAINER

15154-MM5-000

$6.60

8

GUIDE, OIL PUMP CHAIN

15171-MCA-000

$8.84

9

VALVE ASSY., RELIEF

15220-MY9-000

$42.89

10

COLLAR (16X18X10)

15326-KBV-000

$4.44

11

BOLT, FLANGE (6X60)

90011-MW3-601

$6.39

12

BOLT, FLANGE (6X14) (CT200)

90014-952-000

$2.35

13

BOLT-WASHER (6X12)

90021-MM5-000

$5.12

14

WASHER, THRUST (11MM)

90456-333-000

$2.53

15

OIL SEAL (11X15X3) (KOYO)

91208-MN1-771

$8.66

16

O-RING (18X3) (ARAI)

91302-KE8-003

$2.61

17

O-RING (14.8X2.2) This part replaces 91313-MB0-003.

91313-MG7-004

$3.67

17

O-RING (14.8X2.2)

91313-MG7-004

$3.67

18

O-RING (7.8X1.9) (NOK)

91352-SA5-952

$2.68

19

PIN, DOWEL (8X14)

94301-08140

$2.25

20

BOLT, FLANGE (6X16)

95701-06016-08

$1.49

21

BOLT, FLANGE (6X38)

95701-06038-08

$1.80

22

ROLLER (4X15.8)

96220-40158
