Honda GL1500IA (93) GOLD WING INTERSTATE, USA, VIN# 1HFSC226-PA500001 STEP (I) Diagram

#

Description
Price

1

RUBBER, RADIATOR MOUNTING

19113-MB1-870

$3.47

2

PIN, STEP BAR JOINT

50603-KB4-000

$4.84

3

PIN, STEP PIVOT

50603-MN5-000

Unavailable

4

BAR, R. STEP

50612-MT2-000

$57.36

5

SPRING, STEP RETURN

50617-MB1-700

$5.80

6

COVER, STEP (LOWER)

50619-MN5-000

$25.90

7

STEP ASSY., R. MAIN (NOT AVAILABLE)

50630-MT2-000

Unavailable

8

STEP ASSY., L. MAIN (NOT AVAILABLE)

50640-MT2-000

Unavailable

9

BAR, L. STEP

50642-MT2-000

$57.36

10

RUBBER, MAIN STEP

50661-MN5-000

$20.38

11

BAR, R. PILLION STEP

50711-MM8-000

Unavailable

12

BAR, L. PILLION STEP

50712-MM8-000

Unavailable

13

RUBBER, PILLION STEP

50713-MK7-000

Unavailable

14

WASHER, PILLION STEP

50714-MK7-000

$5.05

15

HOLDER, R. PILLION STEP

50715-MW5-870

Unavailable

16

COVER, R. PILLION STEP HOLDER

50717-MW5-000

$71.74

17

SUB-COVER, R. PILLION STEP HOLDER

50725-MW5-870

Unavailable

18

SUB-COVER, L. PILLION STEP HOLDER

50726-MW5-870

Unavailable

19

HOLDER, L. PILLION STEP

50815-MW5-870

Unavailable

20

COVER, L. PILLION STEP HOLDER

50817-MW5-000

$71.74

21

CAP, RR. BUMPER

84103-443-611

$4.23

22

BOLT, FLANGE (6MM)

90111-GK1-000

Unavailable

23

BOLT, HEX. (6X12)

90113-MW5-870

Unavailable

24

COLLAR, RR. SPLASH GUARD

90325-197-000

$3.41

25

BOLT, CAP (6X8)

92501-06008-0B

Unavailable

26

BOLT-WASHER (6X20)

93403-06020-00

$2.00

27

WASHER, PLAIN (8MM)

94102-08000

$1.49

28

PIN, COTTER (1.6X25) This part replaces 94201-16150.

94201-16250

$1.49

28

PIN, COTTER (1.6X25)

94201-16250

$1.49
