Honda GL1500IA (93) GOLD WING INTERSTATE, USA, VIN# 1HFSC226-PA500001 REAR CASE Diagram

BUSH, ENGINE HANGER (B)

11141-MN5-000

Unavailable

CAP, OIL FILLER

15611-MB0-000

$8.54

TUBE, BREATHER

15761-MN5-000

Unavailable

CLIP, AIR HOSE (21.5)

18532-634-670

$7.39

CASE, RR.

21110-MW5-870

Unavailable

GASKET, RR. CASE

21112-MN5-650

$39.24

BODY, SCAVENGE OIL PUMP STRAINER

21116-MT8-000

Unavailable

CAP, SCAVENGE OIL PUMP STRAINER

21117-MT8-000

Unavailable

PLATE, PRIMARY BEARING SETTING

21122-MN5-000

$8.88

HOLDER, FINAL SHAFT BEARING

23751-MN5-000

$102.12

BEARING, RADIAL BALL (6010) (NTN)

91002-MN5-003

$70.43

OIL SEAL (28X48X9) (NOK)

91204-MN5-005

$12.15

O-RING (62.4X3.1) This part replaces 91304-MN5-003.

91316-PE7-730

$5.30

O-RING (62.4X3.1)

91316-PE7-730

$5.30

O-RING (62.4X3.1) This part replaces 91316-PT6-003.

91316-PE7-730

$5.30

O-RING (21.5X3.2)

91307-425-003

$2.55

PIN, DOWEL (10X16)

94301-10160

$2.24

BOLT, FLANGE (6X16)

95701-06016-08

$1.32

BOLT, FLANGE (8X28)

95701-08028-08

$1.91

BOLT, FLANGE (8X45)

95701-08045-08

$2.01

BOLT, FLANGE (8X55)

95701-08055-08

$2.17
