Honda GL1500IA (93) GOLD WING INTERSTATE, USA, VIN# 1HFSC226-PA500001 REAR BRAKE MASTER CYLINDER Diagram

#

Description
Price

2

CLAMP A, RR. BRAKE HOSE

43156-MN5-000

Unavailable

3

CLAMP B, RR. BRAKE HOSE (B)

43157-MN5-000

Unavailable

4

PIPE ASSY., RR. BRAKE MASTER CYLINDER (B)

43300-MY4-000

Unavailable

5

HOSE, RR. BRAKE (A) (NICHIRIN)

43310-MT8-003

Unavailable

6

HOSE, RR. BRAKE (B) (NICHIRIN)

43313-MT8-003

$20.18

7

PIPE, RR. BRAKE

43314-MN5-000

Unavailable

8

PIPE ASSY., RR. BRAKE MASTER CYLINDER (A)

43320-MY4-000

Unavailable

9

JOINT A, MASTER CYLINDER PIPE

43321-MY4-003

$36.15

10

MASTER CYLINDER ASSY., RR. (NOT AVAILABLE)

43500-MW5-871

Unavailable

11

CONNECTOR, MASTER CYLINDER (NISSIN)

43503-MN5-006

$13.38

12

BOOT

43504-MB2-006

$9.24

13

CUP, MASTER CYLINDER OIL (NISSIN)

43511-MN5-006

Unavailable

14

HOSE, RR. MASTER CYLINDER

43512-MN5-000

Unavailable

15

CAP, OIL CUP

43513-MB4-672

Unavailable

16

PISTON SET, MASTER CYLINDER (NISSIN)

43520-MG9-305

$62.11

17

ROD, PUSH (NISSIN)

43530-MN5-006

$27.09

22

HOSE, L. FR. BRAKE (NICHIRIN)

45124-MT8-003

Unavailable

23

CLAMP, MASTER CYLINDER OIL HOSE

45514-KV3-006

$14.51

24

DIAPHRAGM

45520-371-013

$13.07

25

PLATE, DIAPHRAGM

45521-MJ6-006

$3.87

26

CIRCLIP

46182-500-013

$4.53

27

PIN D, JOINT This part replaces 46503-KW3-000.

95015-54000

$4.05

27

PIN D, JOINT

95015-54000

$4.05

28

JOINT, BRAKE ROD

46504-MT8-006

$8.37

29

BRACKET, FR. BRAKE HOSE

50301-MN5-000

Unavailable

30

BRACKET, RR. BRAKE HOSE

50302-MN5-000

Unavailable

31

BOLT, OIL (10X22) This part replaces 90145-MS9-611.

90145-MS9-612

$6.99

31

BOLT, OIL (10X22)

90145-MS9-612

$6.99

32

WASHER, OIL BOLT

90545-300-000

$6.56

33

CLIP, BRAKE HOSE

90651-538-000

$6.46

34

O-RING (14.8X2.4)

91212-422-006

$2.37

36

SCREW-WASHER (4X12)

93893-04012-08

$1.24

36

SCREW-WASHER (4X12) This part replaces 93893-04012-18.

93893-04012-08

$1.24

37

NUT, HEX. (8MM)

94002-08000-0S

$1.21

37

NUT, HEX. (8MM) This part replaces 94002-08080-0S.

94002-08000-0S

$1.21

38

PIN, SPLIT (2.0X15)

94201-20150

$0.96

39

BOLT, FLANGE (6X12)

95701-06012-08

$1.50

40

BOLT, FLANGE (6X25)

95701-06025-08

$1.66
