Honda GL1500AA (00) GOLD WING ASPENCADE, USA, VIN# 1HFSC220-YA200001 REAR BRAKE MASTER CYLINDER Diagram

#

Description
Price

1

SWITCH ASSY., RR. STOP & CRUISE

35355-MT8-003

Unavailable

2

CLAMP, RR. BRAKE HOSE (A)

43156-MN5-000

Unavailable

3

CLAMP B, RR. BRAKE HOSE (B)

43157-MN5-000

Unavailable

4

PIPE ASSY., RR. BRAKE MASTER CYLINDER (B)

43300-MY4-000

Unavailable

5

HOSE A, RR. BRAKE

43310-MAM-L41

Unavailable

6

HOSE, RR. BRAKE (B) (NICHIRIN)

43313-MT8-003

$22.49

7

PIPE, RR. BRAKE

43314-MN5-000

Unavailable

8

PIPE ASSY., RR. BRAKE MASTER CYLINDER (A)

43320-MY4-000

Unavailable

9

JOINT A, MASTER CYLINDER PIPE

43321-MY4-003

$39.13

10

CONNECTOR, MASTER CYLINDER (NISSIN)

43503-MN5-006

$14.92

11

BOOT

43504-MB2-006

$10.04

12

MASTER CYLINDER SUB-ASSY., RR. (NISSIN)

43510-MT8-305

$292.17

13

CUP, MASTER CYLINDER OIL (NISSIN)

43511-MN5-006

Unavailable

14

HOSE, RR. MASTER CYLINDER

43512-MN5-000

Unavailable

15

CAP, OIL CUP

43513-MY1-006

$29.39

16

PISTON SET, MASTER CYLINDER (NISSIN)

43520-MG9-305

$67.65

17

ROD, PUSH (NISSIN)

43530-MN5-006

$29.33

18

BRACKET, SWITCH (NISSIN)

43535-MN5-006

Unavailable

19

PLATE, SWITCH (NISSIN)

43537-MN5-006

$4.39

20

SPRING, SWITCH (NISSIN)

43538-MN5-006

Unavailable

21

NUT, SWITCH PLATE (NISSIN)

43539-MN5-006

$4.11

22

HOSE, L. FR. BRAKE

45124-MAM-L41

Unavailable

23

CLAMP, MASTER CYLINDER OIL HOSE

45514-KV3-006

$15.70

24

DIAPHRAGM

45520-371-013

$14.15

25

PLATE, DIAPHRAGM

45521-MJ6-006

$4.06

26

CIRCLIP

46182-500-013

$4.90

27

JOINT, BRAKE ROD

46504-MT8-006

$9.05

28

BRACKET, FR. BRAKE HOSE

50301-MN5-000

Unavailable

29

BRACKET, RR. BRAKE HOSE

50302-MN5-000

Unavailable

30

BOLT, OIL (10X22)

90145-MS9-612

$7.54

31

WASHER, OIL BOLT

90545-300-000

$3.99

32

CLIP, BRAKE HOSE

90651-538-000

$6.77

33

O-RING (14.8X2.4)

91212-422-006

$2.56

34

SCREW-WASHER (4X14)

93891-04014-08

$1.49

35

SCREW-WASHER (4X12)

93893-04012-07

$1.49

35

SCREW-WASHER (4X12) This part replaces 93893-04012-17.

93893-04012-07

$1.49

36

NUT, HEX. (8MM)

94002-08000-0S

$1.49

36

NUT, HEX. (8MM) This part replaces 94002-08080-0S.

94002-08000-0S

$1.49

37

PIN, SPLIT (2.0X15)

94201-20150

$1.49

38

PIN D, JOINT

95015-54000

$4.24

39

BOLT, FLANGE (6X12)

95701-06012-08

$1.67

40

BOLT, FLANGE (6X25)

95701-06025-08

$1.72
