Honda GL1200IAC (84) GOLD WING INTERSTATE, USA, VIN# 1HFSC144-EA010761 TO 1HFSC144-EA032091 GL1200I INSTRUMENTS 84-85 Diagram

#

Description
Price

1

RUBBER, RADIATOR MOUNTING

19051-KA4-000

$3.80

2

COLLAR, RADIATOR MOUNTING

19052-MB0-000

$6.34

3

BULB 12V 2.3W WED This part replaces 34908-MB0-003.

34275-S2X-003

$3.28

4

INSTRUMENT ASSY., COMBINATION | Use up to Frame SN EA024000 This part replaces 37100-MG9-770.

37100-MG9-772

Unavailable

4

INSTRUMENT ASSY., COMBINATION | Use up to Frame SN EA024000 This part replaces 37100-MG9-771.

37100-MG9-772

Unavailable

4

INSTRUMENT ASSY., COMBINATION

37100-MG9-772

Unavailable

6

GLASS, INSTRUMENT (NOT AVAILABLE) | Use up to Frame SN EA024000

37102-MG9-771

Unavailable

6

GLASS, METER (NOT AVAILABLE) | Use from Frame SN EA024001

37102-MG9-772

Unavailable

7

PLATE, REFLECTING | Use up to Frame SN EA024000

37103-MG9-771

Unavailable

7

PLATE, REFLECTING | Use from Frame SN EA024001

37103-MG9-772

Unavailable

8

CASE, METER

37104-MG9-731

Unavailable

8

CASE, METER This part replaces 37104-MG9-771.

37104-MG9-731

Unavailable

11

STAY, METER SETTING

37120-MG9-771

Unavailable

12

SPEEDOMETER ASSY. (NOT AVAILABLE) This part replaces 37200-MG9-771.

37200-MG9-741

Unavailable

13

RUBBER, METER SETTING (NOT AVAILABLE)

37203-MC7-611

Unavailable

14

KNOB, TRIP METER (NOT AVAILABLE)

37204-MC7-612

Unavailable

15

SWITCH, LEAD (NOT AVAILABLE)

37240-MG9-771

Unavailable

16

TACHOMETER ASSY. This part replaces 37250-MG9-771.

37250-MG9-761

Unavailable

17

RUBBER, TACHOMETER (NOT AVAILABLE)

37253-MC7-611

Unavailable

18

METER ASSY., TEMPERATURE & FUEL (NOT AVAILABLE) This part replaces 37300-MG9-771.

37300-ML8-671

Unavailable

19

COLLAR, TEMPERATURE & FUEL METER (NOT AVAILABLE)

37303-MC7-611

Unavailable

20

COLLAR, METER (NOT AVAILABLE)

37303-MG9-771

Unavailable

21

STAY, TEMPERATURE & FUEL METER

37304-MG9-771

Unavailable

22

RUBBER, CUSHION (NOT AVAILABLE)

37404-KG4-008

Unavailable

23

WIRE, PILOT (NOT AVAILABLE)

37619-MG9-771

Unavailable

24

CABLE ASSY., SPEEDOMETER

44830-ME5-000

Unavailable

25

CABLE (INNER) (NOT AVAILABLE)

44831-ME5-300

Unavailable

26

WASHER (4.3X12.5) (NOT AVAILABLE)

90101-MC7-611

Unavailable

27

SCREW, FLAT (2.3X8) (NOT AVAILABLE) This part replaces 90600-MC7-611.

90600-MC7-612

Unavailable

27

SCREW, FLAT (2.3X8) (NOT AVAILABLE)

90600-MC7-612

Unavailable

28

SCREW-WASHER (3X24)

90890-MG9-771

Unavailable

29

SCREW-WASHER (3X12)

90102-MT8-008

Unavailable

29

SCREW-WASHER (3X12) This part replaces 90891-MG9-771.

90102-MT8-008

Unavailable

30

O-RING (6.8X1.9) This part replaces 91301-027-000.

91306-PJ4-000

$3.01

30

O-RING (6.8X1.9)

91306-PJ4-000

$3.01

30

O-RING (6.8X1.9) This part replaces 91310-MC7-003.

91306-PJ4-000

$3.01

31

SCREW, PAN (4X6)

93500-04006-0A

$1.49

32

SCREW, PAN (4X10)

93500-04010-0H

$1.49

33

SCREW, OVAL (5X20)

93700-05020-0A

$1.49

34

NUT, HEX. (6MM) This part replaces 94001-06000-0S.

94001-06200-0S

$1.49

34

NUT, HEX. (6MM)

94001-06200-0S

$1.49

35

NUT, HEX. (4MM)

94002-04000-0S

$1.49

36

NUT, CAP (6MM) This part replaces 94021-06000-0S.

94021-06020

$1.73

36

NUT, CAP (6MM)

94021-06020

$1.73

36

NUT, CAP (6MM) This part replaces 94021-06020-0S.

94021-06020

$1.73

36

NUT, CAP (6MM) This part replaces 94022-06020.

94021-06020

$1.73

37

NUT, FLANGE (6MM)

94050-06080

$1.49

38

WASHER, PLAIN (4MM)

94101-04000

$1.49

39

WASHER, PLAIN (6MM)

94103-06000

$1.49

40

WASHER, SPRING (4MM)

94111-04800

$1.49
