Yamaha FZR1000BC (FZR1000 CA) 1991 ELECTRICAL 2 Diagram

#

Description
Price

1

STARTER RELAY ASSY

36Y-81940-00-00

Unavailable

2

NUT, FLANGE(7NB)

95780-06500-00

$2.60

3

YTX14BS YUASA BATTERY - SA

YTX-14BS0-00-00

Unavailable

4

SEAT, BATTERY

5Y1-82122-00-00

$7.99

5

BAND, BATTERY

2T4-82131-00-00

$8.99

6

WIRE, PLUS LEAD

3GM-82115-50-00

Unavailable

7

WIRE,MINUS LEAD

3XW-82116-00-00

Unavailable

8

MAIN SWITCH STEERING LOCK

3JV-82501-00-00

Unavailable

9

SCREW(1KT)

90149-06228-00

$9.49

10

STOP SWITCH ASSEMBLY

3GM-82530-11-00

Unavailable

11

WIRE HARNESS ASSEMBLY

3LK-82590-10-00

Unavailable

12

FUSE (12V 30A)

1AE-82151-00-00

$7.99

13

FUSE (10A)

42X-82151-00-00

$4.32

14

FUSE (20A)

2GV-82151-00-00

$5.49

15

WIRE, SUB LEAD

3GM-82509-00-00

Unavailable

16

BAND, SWITCH CORD

437-83936-01-00

Unavailable

17

BAND, SWITCH CORD

437-83936-11-00

Unavailable

17

BAND, SWITCH CORD

437-83936-11-00

Unavailable

18

BAND

1UA-82591-00-00

Unavailable

19

CLAMP(4FM)

90464-15195-00

Unavailable

20

CLAMP(4FM)

90464-15195-00

Unavailable

21

BAND, SWITCH CORD

437-83936-01-00

Unavailable

22

BAND, SWITCH CORD

25G-83936-01-00

Unavailable

23

RELAY ASSY

3EN-81950-02-00

Unavailable

24

RELAY ASSEMBLY

3GM-81950-10-00

Unavailable

25

RESISTOR ASSEMBLY

3KS-85370-00-00

Unavailable

26

. SCREW, FLAT HEAD

98780-05016-00

Unavailable

27

NUT, FLANGE(3GM)

95707-05500-00

Unavailable

28

SWITCH

3TJ-83964-10-00

Unavailable

29

SWITCH, SIDE STAND

2KT-82566-01-00

Unavailable

30

SCREW, FLAT

98707-05016-00

Unavailable

31

SCREW, W/WASHER (4L0)

90159-06060-00

Unavailable

32

CLAMP

5Y9-12491-00-00

Unavailable
