Yamaha FZ10HGY (FZ10) B6720 2017 STEERING Diagram

#

Description
Price

1

BEARING

93399-99957-00

$70.99

2

SEAL, STEERING

3FV-23462-00-00

$24.99

3

BEARING(3FV)

93399-99932-00

$63.99

4

COVER, BALL RACE 1

4XV-23415-01-00

$24.99

5

NUT

90179-30691-00

$33.99

6

WASHER, SPECIAL

4XV-23418-00-00

$17.49

7

WASHER, PLATE

90202-30235-00

$8.49

8

NUT

90170-28419-00

$40.99

9

WASHER, PLATE

90201-281U8-00

$11.49

10

BOLT

90109-08196-00

$8.49

11

GUIDE, CABLE

B67-23389-00-00

Unavailable

12

CLAMP

90464-16006-00

$9.49

13

CLAMP

90465-10098-00

Unavailable

14

CROWN, HANDLE

B67-23435-00-00

$192.99

15

BOLT,SOCKET

91314-08030-00

$2.34

16

HOLDER, HANDLE UPP

2BS-23441-00-00

Unavailable

17

HOLDER, HANDLE UPP

2BS-2344A-00-00

Unavailable

18

BOLT,SOCKET

91314-08030-00

$2.34

19

PLUG(42X)

90338-08163-00

Unavailable

20

HOLDER 1

B67-24847-01-00

Unavailable

21

HOLDER 2

B67-24848-01-00

Unavailable

22

NUT, S/L FLANGE

95602-10200-00

Unavailable

23

HANDLEBAR SHIMMY DAMPER ASSY

B67-23490-00-00

Unavailable

24

BAND

1UA-82591-00-00

Unavailable

25

NUT, SELF-LOCKING

95602-08200-00

Unavailable

26

BOLT, FLANGE

95812-08030-00

Unavailable

27

WASHER (1T1)

90201-08649-00

Unavailable

28

WASHER

5VY-26398-00-00

Unavailable
