Yamaha FX700T (FX-1) 1995 FUEL Diagram

#

Description
Price

1

HOSE (L1040)

90445-10MA9-00

$56.27

2

HOSE (L400)

90445-10M43-00

$5.96

3

FILTER ASSY

6K8-24560-21-00

$28.64

4

FUEL COCK ASSY 1

6K8-24500-03-00

Unavailable

5

HOSE (L1700)

90445-10M87-00

Unavailable

6

HOSE (L1700)

90445-10M87-00

Unavailable

7

HOSE (L400)

90445-10M43-00

$5.96

8

CLAMP

90465-10098-00

$1.68

9

LEVER, COCK

6R7-24524-00-00

$7.03

10

BRACKET, FUEL FILTER

FN8-67816-00-00

$16.99

11

RIVET, BLIND

90267-48940-00

$10.99

12

HOLDER

EU0-67817-00-00

$13.33

13

SCREW, BIND

98980-04008-00

$3.05

14

NUT, HEXAGON (1E6)

90170-22187-00

$7.77

15

HOLDER, PIPE 1

EW2-67811-00-00

Unavailable

16

RIVET, BLIND

90267-489UE-00

Unavailable

17

CLIP (EW2)

90601-20010-00

Unavailable

18

CLAMP COMP (EU0)

90600-91736-00

Unavailable

19

. WASHER, PLAIN

90201-05925-00

Unavailable
