Yamaha FX1900AB (CRUISER HO) F7K4 2025 ELECTRICAL 2 Diagram

RECTIFIER & REGULATOR ASSY

6EK-81960-10-00

$163.35

PLATE, RECTIFIER FITTING

6ET-81975-01-00

$6.18

COVER, RECTIFIER

6LE-81972-00-00

$197.04

BOLT, WITH WASHER

90119-06MA4-00

$3.42

COLLAR

90387-08M37-00

$9.68

BOLT, WITH WASHER

90119-08187-00

$2.82

GROMMET

90480-22M15-00

$11.01

IGNITION COIL ASSY

6S5-82310-10-00

$263.06

BOLT,FLANGE (EW2)

90105-06903-00

$4.99

PLUG, SPARK (NGK LFR6A-00)

LFR-6A000-00-00

Unavailable

BAND

1UA-82591-00-00

$3.85

THERMO UNIT

52B-H3591-00-00

Unavailable

SENSOR, CAM POSITION

60E-85896-02-00

$137.65

BOLT,SOCKET

91380-06016-00

Unavailable

OIL PRESSURE SWITCH ASSY

68V-82504-00-00

$30.45

LEAD WIRE ASSY

6S5-81315-01-00

Unavailable

THERMOSENSOR ASSY

6AA-85790-00-00

$103.73

CLAMP

90464-20005-00

$2.13

CLAMP

90464-31002-00

Unavailable
