Yamaha FX1800JX (FX HO WITH AUDIO_FX HO) F3VA 2022 BILGE PUMP Diagram

#

Description
Price

1

NUT, DRAIN 1

F3X-U224B-00-00

$0.93

2

BODY, DRAIN 1

F3X-U224C-00-00

$1.58

3

GASKET

F3X-U7564-00-00

$1.23

4

JOINT,HOSE

F3X-U7857-00-00

$2.30

5

CHECK VALVE

F3X-U7767-00-00

$14.35

6

JOINT, DRAIN

F3X-U7617-00-00

$1.58

7

HOSE, DRAIN 2

F3X-U7629-10-00

$11.18

8

HOSE, DRAIN

F3X-U2249-10-00

$12.67

9

HOSE, DRAIN 3

F3X-U7628-10-00

$2.61

10

HOSE 1

F3X-U7626-10-00

$4.93

11

CLAMP

90464-32801-00

$1.29

12

BAND

90601-200U1-00

$2.77

13

BASE, CLAMP

F1W-U828M-00-00

$1.29

14

TUBE

6EX-U773D-00-00

$4.10

15

RIVET, BLIND

90267-48802-00

$1.98

16

CLIP

90467-17802-00

$3.02

17

PLUG,DRAIN

F4P-U2255-00-00

$1.43

18

BAND

90601-200U1-00

$2.77

19

CONNECTOR

F3X-U8377-00-00

$1.51

20

HOSE, DRAIN

F3X-U2249-10-00

$12.67

21

BAND

90601-200U1-00

$2.77
