Yamaha FX1100ALG (WaveRunner FX Cruiser High Output CA) F1XJ 2008 OIL COOLER Diagram

#

Description
Price

1

CONNECTOR

60E-13446-00-00

$14.44

2

O-RING (1L9)

93210-18322-00

$4.24

3

CASE, OIL COOLER

6B6-13462-00-94

Unavailable

4

BOLT, WITH WASHER

90119-10020-00

$5.91

5

PLATE, BAFFLE

6B6-13317-00-00

$21.95

6

BOLT,SOCKET

91317-05014-00

$6.23

7

STRAINER 2

60E-13421-00-00

$23.99

8

BOLT,SOCKET

91317-06014-00

$6.57

9

CLAMP(6E8)

90465-13M39-00

$4.47

10

BRACKET

6AA-85542-00-00

$2.27

11

COLLAR

90387-06M05-00

$6.45

12

BOLT, HEXAGON W/W DEEP RECESS

97E95-06520-00

$2.29

13

ANODE

6E5-11325-00-00

$4.08

14

SCREW, FLAT HEAD(GA5)

98780-04014-00

$1.97

15

COVER, OIL COOLER

60E-13463-10-94

$442.41

16

PLATE, BREATHER

6B6-11165-00-00

$112.11

17

PLATE, BREATHER 2

6B6-11145-00-00

$19.49

18

BOLT,SOCKET

91317-05035-00

Unavailable

19

GASKET

60E-13477-00-00

$24.23

20

GASKET

60E-13475-00-00

$18.89

21

BOLT, FLANGE

90105-06036-00

$2.27

22

PLATE

67F-82588-00-00

$2.86

23

CLAMP

90464-20012-00

Unavailable

24

PLUG, OIL LEVEL

6BU-15362-A0-00

$37.91

25

O-RING

60E-13473-00-00

$8.32

26

HANGER, ENGINE

6B6-11119-00-00

$10.99

27

BOLT, WITH WASHER

90119-06023-00

$3.07

28

COVER, OIL COOLER

6D3-13443-00-94

$106.05

29

GASKET

60E-13476-10-00

$22.11

30

BOLT (689)

90105-06M07-00

Unavailable

31

STAY

6B6-13151-00-94

$169.68

32

BOLT, WITH WASHER

90119-10M23-00

$10.24

33

BOLT, STUD

90116-10016-00

$10.99

34

NUT, CAP

90176-10001-00

$3.33

35

PIPE, BREATHER 2

6B6-11167-00-00

$30.29

36

CLIP

90467-170A0-00

$2.80

37

GASKET

60E-13567-00-00

$1.82

38

COVER 2

60E-13882-00-00

$11.35

39

BOLT, WITH WASHER

97580-06516-00

Unavailable

40

BOLT (661)

97013-06012-00

Unavailable

41

WASHER, PLAIN (646)

92990-06600-00

Unavailable

42

BRACKET 1

60E-51341-00-94

$19.68

43

WASHER, PLAIN (646)

92990-06600-00

Unavailable

44

. BOLT

91380-06020-00

$1.86

45

GROMMET(6R7)

90480-06M46-00

Unavailable
