Yamaha FX1100AF (WaveRunner FX Cruiser HO) F1XA 2007 OIL COOLER Diagram

#

Description
Price

1

CONNECTOR

60E-13446-00-00

$14.81

2

O-RING (1L9)

93210-18322-00

$4.46

3

CASE, OIL COOLER

6B6-13462-00-94

Unavailable

4

BOLT, WITH WASHER

90119-10020-00

$5.82

5

PLATE, BAFFLE

6B6-13317-00-00

$21.63

6

BOLT,SOCKET

91317-05014-00

$6.23

7

STRAINER 2

60E-13421-00-00

$23.87

8

BOLT,SOCKET

91317-06014-00

$6.57

9

CLAMP

90465-12M53-00

$4.93

10

COLLAR

90387-06M05-00

$6.83

11

BOLT, HEXAGON W/W DEEP RECESS

97E95-06520-00

$2.39

12

ANODE

6E5-11325-00-00

$4.52

13

SCREW, FLAT HEAD(GA5)

98780-04014-00

$1.97

14

COVER, OIL COOLER

60E-13463-10-94

$435.81

15

PLATE, BREATHER

6B6-11165-00-00

$110.43

16

PLATE, BREATHER 2

6B6-11145-00-00

$19.39

17

BOLT,SOCKET

91317-05035-00

Unavailable

18

GASKET

60E-13477-00-00

$23.87

19

GASKET

60E-13475-00-00

$19.37

20

BOLT, FLANGE

90105-06036-00

$2.24

21

PLUG, OIL LEVEL

6BU-15362-A0-00

$37.32

22

O-RING

60E-13473-00-00

$8.19

23

HANGER, ENGINE

6B6-11119-00-00

$10.99

24

BOLT, WITH WASHER

90119-06023-00

$3.21

25

COVER, OIL COOLER

6D3-13443-00-94

$104.46

26

GASKET

60E-13476-10-00

$21.53

27

BOLT (689)

90105-06M07-00

Unavailable

28

STAY

6B6-13151-00-94

$167.15

29

BOLT, WITH WASHER

90119-10M23-00

$10.04

30

BOLT, STUD

90116-10016-00

$10.99

31

NUT, CAP

90176-10001-00

$3.41

32

PIPE, BREATHER 2

6B6-11167-00-00

$29.84

33

CLIP

90467-170A0-00

$2.80

34

GASKET

60E-13567-00-00

$1.72

35

COVER 2

60E-13882-00-00

$11.18

36

BOLT, WITH WASHER

97580-06516-00

Unavailable

37

BOLT (661)

97013-06012-00

Unavailable

38

WASHER, PLAIN (646)

92990-06600-00

Unavailable

39

BRACKET 1

60E-51341-00-94

$19.39

40

WASHER, PLAIN (646)

92990-06600-00

Unavailable

41

. BOLT

91380-06020-00

$1.94

42

GROMMET(6R7)

90480-06M46-00

Unavailable
