Yamaha FX10MTRYW (FX NYTRO MTX) 8HA90 2009 INSTRUMENT PANEL Diagram

#

Description
Price

1

PANEL, INSTRUMENT

8GL-77711-00-00

Unavailable

1

PANEL, INSTRUMENT

8GL-77711-30-00

$57.35

2

GROMMET

8GL-77746-00-00

$13.69

3

RIVET

90269-08006-00

$2.72

4

DAMPER

8GL-78316-01-00

$7.62

5

PANEL, INSTRUMENT

8GL-77712-00-00

Unavailable

6

RIVET

90269-08006-00

$2.72

7

COVER, SIDE 1

8GL-21711-00-00

$83.66

8

COVER, SIDE 2

8GL-21721-00-00

$83.66

9

PLATE, SPRING

4XV-2177L-01-00

$6.20

10

RIVET

90269-08006-00

$2.72

11

DAMPER

8GL-78305-00-00

$3.86

12

COVER, STEERING SHAFT 1

8GL-77732-00-00

$15.05

13

LABEL, WARNING 1

8GL-77761-E0-00

Unavailable

14

LABEL, WARNING 1

8GP-77761-00-00

$8.37

15

LABEL, NOTICE TRACK

8HA-2815M-E0-00

Unavailable

16

RIVET

90269-08005-00

$2.69
