Yamaha FX10MTRYW (FX NYTRO MTX) 8HA90 2009 BUMPER Diagram

#

Description
Price

1

BUMPER, FRONT 1

8GL-77511-00-00

$286.37

2

BOLT, FLANGE

95812-08020-00

$1.69

3

BUMPER, REAR 1

8GL-77541-01-00

Unavailable

4

BOLT, FLANGE

95812-08020-00

$1.69

5

PLUG (7Y6)

90338-21145-00

$11.69

6

RIVET, BLIND

90267-47200-00

$2.28

7

COVER, SIDE 3

8GL-21731-00-00

$68.97

8

COVER, SIDE 4

8GL-21741-00-00

$75.92

9

RIVET

90269-08006-00

$2.72

10

COVER, TAIL

8GL-24756-00-00

$62.52

11

SCREW, BINDING

90154-06009-00

$2.92

12

COVER, TAILLIGHT

8GL-84516-00-00

$26.78

13

COVER

8FS-84544-00-00

Unavailable

14

BOLT

90109-06174-00

$7.35

15

PROTECTOR 1

8GL-77551-00-00

$45.12

16

PROTECTOR 2

8GL-77552-00-00

Unavailable

17

PROTECTOR 3

8GL-77553-00-00

$5.77

18

PROTECTOR 4

8GL-77554-00-00

$5.77

19

PROTECTOR 5

8GL-77555-00-00

$1.91

20

PROTECTOR 5

8GL-77555-10-00

$1.07

21

PROTECTOR 6

8GL-77556-00-00

$48.94

22

PROTECTOR 7

8GL-77557-00-00

$1.54

23

TAPE 1

8GL-7717E-00-00

$1.02

24

LINING, SHROUD 1

8GL-77261-00-00

Unavailable

25

FLAP

8GT-K7595-00-00

Unavailable
