Find the part on the Bumper diagram for your 2012 Yamaha FX Nytro (FX10BL), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2012 Yamaha FX Nytro (FX10BL) Bumper Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

BUMPER, FRONT 1

8GL-77511-00-00

1

$286.37

In stock

2

BOLT, FLANGE

95812-08020-00

1

$1.69

In stock

3

BUMPER, REAR 1

8HK-77541-00-00

—

$200.98

In stock

4

BOLT, FLANGE

95812-08020-00

1

$1.69

In stock

5

PLUG (7Y6)

90338-21145-00

1
Out of stock

6

STOPPER, FLAP

8GL-77596-00-00

—

$37.00

In stock

7

RIVET, BLIND

90267-47195-00

1

$3.33

In stock

8

RIVET, BLIND

90267-47200-00

1
Out of stock

9

COVER, SIDE 3

8GL-21731-00-00

—

$68.97

In stock

10

COVER, SIDE 4

8GL-21741-00-00

—

$75.92

In stock

11

RIVET

90269-08006-00

1

$2.72

In stock

12

COVER, TAIL

8GL-24756-00-00

—
Out of stock

13

SCREW, BINDING

90154-06009-00

1

$2.92

In stock

14

COVER, TAILLIGHT

8GL-84516-00-00

—

$26.78

In stock

15

BOLT

90109-06174-00

1
Out of stock

16

PROTECTOR 1

8GL-77551-00-00

—

$101.15

In stock

17

PROTECTOR 2

8GL-77552-00-00

—
Out of stock

18

PROTECTOR 3

8GL-77553-00-00

—

$5.77

In stock

19

PROTECTOR 4

8GL-77554-00-00

—

$5.77

In stock

20

PROTECTOR 5

8GL-77555-00-00

—

$3.12

In stock

21

PROTECTOR 5

8GL-77555-10-00

—

$1.07

In stock

22

PROTECTOR 6

8GL-77556-00-00

—

$48.94

In stock

23

PROTECTOR 7

8GL-77557-00-00

—

$1.54

In stock

24

TAPE 1

8GL-7717E-00-00

—

$1.02

In stock

25

LINING, SHROUD 1

8GL-77261-00-00

—
Out of stock

26

FLAP

8GT-K7595-00-00

1
Out of stock
