Polaris FTR 1200 CARBON ALL OPTIONS (R03) - N22RZR25A8/B8/C8/E8 DRIVE TRAIN, CLUTCH AND RELATED - N22RZR25 (200547C) Diagram

#

Description
Price

-

K-CLUTCH PACK (INCL. 12-15)

2208055

Unavailable

1

SCREW-HXFL-M6X1.0X30,8.8

7520820

Unavailable

2

PLATE-STOPPER

5266812

Unavailable

3

SPRING-CLUTCH,350N

7044950

Unavailable

4

PLATE-PRESSURE,CLUTCH

5141744

Unavailable

5

SEAT-SPRING,CLUTCH

5262709

Unavailable

6

RING-RETAINING,INTERNAL,1.875"

7710651

Unavailable

7

BEARING-BALL,12X32X10,6201NR [MUST ORDER ASM 1205702]

-------

Unavailable

8

PLATE-CLUTCH LIFTER,MACH [MUST ORDER ASM 1205702]

-------

Unavailable

9

SHAFT-CLUTCH LIFTER

6231087

Unavailable

10

NUT-HEX,M20X1.5,32 A/F,STAKING

7547477

Unavailable

11

WASHER-FLAT,ISO7415-M20,HARD

7556518

Unavailable

12

CLUTCH-FRICTION B

1323373

Unavailable

12

CLUTCH-FRICTION B

1323373

Unavailable

13

CLUTCH-SEPARATOR B

5262708

Unavailable

14

DISK-SEPERATOR,CLUTCH,2MM

5266898

Unavailable

15

DISK-FRICTION,A

1323512

Unavailable

16

SPRING, JUDDER, CLUTCH

7044118

Unavailable

17

SEAT, JUDDER SPRING

5258192

Unavailable

18

HUB-INNER,CLUTCH

5141743

Unavailable

19

CLUTCH-THRUST WASHER

7556798

Unavailable

20

COLLAR-BEARING,CLUTCH

5138940

Unavailable

21

SPACER, CLUTCH

5138726

Unavailable

22

ASM., BASKET-OUTER,CLUTCH

1334409

Unavailable

23

SCREW-HXFL-M6X1.0X20 8.8 ZPC

7518141

$4.79

24

WASHER-6.4X20.0X1.6 01

7556054

$10.39

25

ASM., ROLLER FOLLOWER LH

1333426

Unavailable

26

SPRING-TORSION,LH,DETENT

7045544

Unavailable

27

STAR, SHIFTER

5137944

Unavailable

28

WASHER, STAR

7556749

Unavailable

29

SCREW-TORBH-M6X1.0x35 8.8 ZPY C

7520597

$3.99

30

ASM., SHIFTER RATCHET (INCL. 42)

1333461

Unavailable

31

RING-RETAINING,EXTERNAL,12MM

7710645

$1.49

32

WASHER-THRUST,12.20X18.00X1.00

7555977

$7.19

33

SEAL SHAFT, 12X22X7

3610154

Unavailable

34

ASM., GEAR, CRANKSHAFT

1333532

Unavailable

35

WASHER-FLAT,ISO7415-M17,HARD

7557088

Unavailable

36

SPUD-CENTERFEED,CRANKSHAFT

5141636

Unavailable

37

ASM-SHIFT DRUM,6-SPEED

1334511

Unavailable

38

ASM., CLUTCH,BRKT,LEVER,BLK (SEE "CONTROLS, CLUTCH LEVER ASM.")

1323721-463

Unavailable

39

CABLE-CLUTCH,8MM

7082358

Unavailable

40

BEARING-BALL,25X37X7

3513511

Unavailable

41

WASHER-FLAT,12.25X30"

7556748

Unavailable

42

SPACER, SPRING, RATCHET

5138274

Unavailable

43

WASHER-PILOT,6.5X15X1.0

7556780

Unavailable

44

ASM., CLUTCH LIFTER (INCL. 7,8)

1205702

Unavailable

45

ASM-CLUTCH (INCL. 1-5,12-20,22)

1334408

Unavailable
