Ski-Doo Formula Deluxe 380/500, 2000 08- Front Arm Diagram

#

Description
Price

1

Helicoidal Lock Washer M10 | XT Models

234101601

$1.15

2

Hex. Elastic Stop Nut M8

232581414

$0.56

3

SYNTHETIC GREASE, 400 G - Call your local BRP dealership

219700417

Unavailable

4

Hex. Screw M8 X 40

207084044

$1.15

5

WASHER - Call your local BRP dealership

517078700

Unavailable

6

Welded Front Arm

503189311

Unavailable

7

Hardened Washer

503175400

Unavailable

8

SHAFT - Call your local BRP dealership

503190387

Unavailable

9

Shock | Formula S.

503189174

Unavailable

SHOCK - Call your local BRP dealership

503189331

Unavailable

10

Spring

415069900

Unavailable

11

Protector

503193663

$37.99

12

Loctite 243, 10 ml

293800060

$21.49

13

Spring Stopper

706200881

$12.99

14

Axle

503151600

$18.49

15

Lock Washer 8 mm

234181401

$0.92

16

Hex. Screw M8 X 30

207183044

$1.15

17

STOPPER STRAP - Call your local BRP dealership

503190782

Unavailable

18

Lower Axle

503174800

Unavailable

19

GUIDE_SPRING - Call your local BRP dealership

503165100

Unavailable

Spring Guide

503187500

$10.49

20

Bushing

503189324

$14.15

21

HEX. SCREW M10 X 60 - Call your local BRP dealership

207006044

Unavailable

22

Grease Fitting

408200700

$3.49

23

Welded Shock Support

503182100

Unavailable

24

HEX. SCREW M12 X 60 - Call your local BRP dealership

207026044

Unavailable

25

Shock

503188905

Unavailable

Shock

503188973

Unavailable

26

Loctite 271, 10 ml

293800005

$26.99

27

Flat Washer 10 mm

234001410

$1.26

28

Flat Washer 8 mm

234081410

$0.83

29

WASHER - Call your local BRP dealership

503184400

Unavailable

WASHER - Call your local BRP dealership

505070401

Unavailable

30

Flat Washer 12 mm

234021410

$0.72

31

Lock Washer 12 mm

234120602

Unavailable

32

Bushing

414936000

$13.99

CUSHION - Call your local BRP dealership

414802600

Unavailable

33

SHAFT - Call your local BRP dealership

503189313

Unavailable

34

CUSHION - Call your local BRP dealership

503189323

Unavailable

35

HEX. SCREW M12 X 35 - Call your local BRP dealership

207123544

Unavailable

36

Hex. Screw M8 X 25

207182544

$0.90
