Description

Price

1

GASKET, R. REDUCTION COVER

21198-HE0-P00

Unavailable

1

GASKET, R. REDUCTION COVER This part replaces 21198-HE0-000.

21198-HE0-P00

Unavailable

1

GASKET, R. REDUCTION COVER This part replaces 21198-HE0-010.

21198-HE0-P00

Unavailable

2

COVER, R. REDUCTION

21311-HE0-000

Unavailable

3

DISK, CLUTCH FRICTION

22201-HE0-000

Unavailable

4

CLUTCH (OUTER)

22310-HE0-670

Unavailable

5

PLATE, CLUTCH

22311-HE0-000

Unavailable

6

CENTER, CLUTCH

22321-HE0-000

Unavailable

7

PLATE, CLUTCH PRESSURE

22350-115-020

$41.76

8

SPRING, CLUTCH

22401-HE0-000

Unavailable

9

HOLDER, CHANGE CABLE

24721-HE0-000

Unavailable

10

BOLT, SPECIAL FLANGE (6X22)

90050-357-000

$3.35

11

NUT, LOCK (18MM)

90235-429-000

Unavailable

12

WASHER (20MM) (NOT AVAILABLE)

90432-958-000

Unavailable

13

WASHER, THRUST (18MM)

90457-HE0-000

Unavailable

14

WASHER, PLAIN (6MM)

94103-06000

$1.49

15

BOLT, FLANGE (6X14)

95701-06014-00

$1.49

16

BOLT, FLANGE (6X45) This part replaces 95701-06045-00.

95701-06045-07

$2.06

16

BOLT, FLANGE (6X45)

95701-06045-07

$2.06

Honda FL400RA (90) PILOT, JPN, VIN# JH3TE160-LK100001 TORQUE CLUTCH Diagram

GASKET, R. REDUCTION COVER

GASKET, R. REDUCTION COVER This part replaces 21198-HE0-000.

GASKET, R. REDUCTION COVER This part replaces 21198-HE0-010.

COVER, R. REDUCTION

DISK, CLUTCH FRICTION

CLUTCH (OUTER)

PLATE, CLUTCH

CENTER, CLUTCH

PLATE, CLUTCH PRESSURE

SPRING, CLUTCH

HOLDER, CHANGE CABLE

BOLT, SPECIAL FLANGE (6X22)

NUT, LOCK (18MM)

WASHER (20MM) (NOT AVAILABLE)

WASHER, THRUST (18MM)

WASHER, PLAIN (6MM)

BOLT, FLANGE (6X14)

BOLT, FLANGE (6X45) This part replaces 95701-06045-00.

BOLT, FLANGE (6X45)
