Yamaha FJR13ATC (FJR1300ABS CA) 5VSB 2005 STAND FOOTREST Diagram

#

Description
Price

1

STAND, SIDE

5JW-27311-00-00

$190.99

2

COLLAR

90387-10007-00

$12.49

3

BOLT

90101-10025-00

$8.49

4

WASHER, PLAIN(3BM)

92907-10200-00

$4.99

5

NUT, U

95617-10100-00

$8.49

6

BRACKET, SIDE STAND

3P6-27321-00-00

$232.99

7

SPRING, TENSION

90506-20008-00

Unavailable

8

HOSE (L60)

90445-197J2-00

$4.61

9

FOOTREST

4BH-27451-01-00

$58.99

10

SPRING, TORSION

90508-183B9-00

$4.29

11

PIN, CLEVIS

91702-08040-00

$4.35

12

PIN, COTTER

91490-25020-00

$3.19

13

COVER, FOOTREST

3YX-27413-00-00

$29.99

14

ARM 1

5JW-2741A-01-00

$73.99

15

SCREW PAN HEAD W/W (4ST1E,4WC1

97607-05230-00

$8.49

16

WASHER(1RW)

92907-05600-00

Unavailable

17

SCREW, PAN HEAD WITH WASHER

97607-05220-00

Unavailable

18

BOLT

3HE-27435-00-00

Unavailable

19

FOOTREST

4BH-27461-01-00

Unavailable

20

SPRING, TORSION

90508-184B0-00

Unavailable

21

PIN, CLEVIS

91702-08040-00

$4.35

22

PIN, COTTER

91490-25020-00

$3.19

23

COVER, FOOTREST

3YX-27413-00-00

$29.99

24

ARM 1

5JW-2741A-01-00

$73.99

25

SCREW PAN HEAD W/W (4ST1E,4WC1

97607-05230-00

$8.49

26

WASHER(1RW)

92907-05600-00

Unavailable

27

SCREW, PAN HEAD WITH WASHER

97607-05220-00

Unavailable

28

BOLT

3HE-27435-00-00

Unavailable

29

BRACKET 2

5JW-27442-00-00

Unavailable

30

BOLT (3LD)

90109-087F1-00

Unavailable

31

BOLT

90109-10058-00

Unavailable

32

SCREW

90149-10001-00

Unavailable

33

BRACKET 3

5JW-27443-00-00

Unavailable

34

LABEL

3TU-2178A-00-00

Unavailable

35

BOLT, HEXAGON SOCKET HEAD(3GM)

90110-08199-00

Unavailable

36

BUSH, SOLID(3VD)

90380-20213-00

Unavailable

37

FOOTREST, REAR 1

5LV-27431-01-00

Unavailable

38

COVER, FOOTREST

3YX-27413-00-00

$29.99

39

SCREW, PAN HEAD

98507-05014-00

Unavailable

40

BOLT, SOCKET

91314-06040-00

Unavailable

41

NUT, U FLANGE

95604-06200-00

Unavailable

42

SPRING, COMPRESSION

90501-15001-00

Unavailable

43

BALL

93501-04011-00

Unavailable

44

WASHER, SPECIAL

5JJ-27437-01-00

Unavailable

45

COLLAR

90387-06014-00

Unavailable

46

FOOTREST, REAR 2

5LV-27441-01-00

Unavailable

47

COVER, FOOTREST

3YX-27413-00-00

$29.99

48

SCREW, PAN HEAD

98507-05014-00

Unavailable

49

BOLT, SOCKET

91314-06040-00

Unavailable

50

NUT, U FLANGE

95604-06200-00

Unavailable

51

SPRING, COMPRESSION

90501-15001-00

Unavailable

52

BALL

93501-04011-00

Unavailable

53

WASHER, SPECIAL

5JJ-27437-01-00

Unavailable

54

COLLAR

90387-06014-00

Unavailable

55

BRACKET 4

5JW-2741L-00-00

Unavailable

56

BRACKET 5

5JW-2742L-00-00

Unavailable

57

BOLT, HEXAGON SOCKET HEAD(3GM)

90110-08199-00

Unavailable

58

DAMPER, FOOTREST 2

36Y-27424-01-00

Unavailable

59

COLLAR

90387-10048-00

Unavailable

60

WASHER, PLATE (2H7)

90201-10669-00

Unavailable

61

SEAL

5JW-23844-00-00

Unavailable

62

BRACKET, MAIN STAND

5P5-27151-00-00

Unavailable

62

BRACKET, MAIN STAND

5P5-27151-00-00

Unavailable

63

BRACKET, MAIN STAND 2

5P5-27152-00-00

Unavailable

64

BOLT

90101-10004-00

Unavailable

65

NUT, SELF-LOCKING(JN5)

95607-10200-00

Unavailable

66

STAND, MAIN

5JW-27111-03-00

Unavailable

67

STOPPER, MAIN STAND

1A0-27114-00-00

Unavailable

68

BOLT(1TX)

90109-101E6-00

Unavailable

69

NUT, SELF-LOCKING(JN5)

95607-10200-00

Unavailable

70

SPRING, TENSION

90506-40001-00

Unavailable

71

SPRING, TENSION

90506-23001-00

Unavailable

72

HOSE (L0)

90445-170K9-00

Unavailable
