- FJR13ATC (FJR1300ABS CA) 5VSB 2005
RADIATOR HOSE
Yamaha FJR13ATC (FJR1300ABS CA) 5VSB 2005 RADIATOR HOSE Diagram
#
1
RADIATOR ASSY
5JW-12461-00-00
Unavailable
2
CONDUCTION ASSY
5JW-12590-01-00
Unavailable
4
BLOWER ASSY
5JW-12405-01-00
Unavailable
12
HOSE,3
5JW-1243F-00-00
Unavailable
14
DAMPER, AIR SHROUD 2
5JW-12659-00-00
Unavailable
15
DAMPER, AIR SHROUD 3
5JW-12668-00-00
Unavailable
16
GROMMET (29L)
90480-15363-00
Unavailable
17
COLLAR
90387-06039-00
Unavailable
18
WASHER, PLATE(36Y)
90201-063J2-00
Unavailable
19
BOLT, FLANGE
95817-06030-00
Unavailable
20
BOLT, FLANGE
95817-06025-00
Unavailable
21
STAY, RADIATOR
5JW-12464-10-00
Unavailable
22
BOLT, FLANGE
95817-06012-00
Unavailable
23
HOSE 6
5JW-12589-00-00
Unavailable
25
HOSE 7
5JW-12551-00-00
Unavailable
26
HOSE 8
5JW-12552-00-00
Unavailable
27
HOSE CLAMP ASSY(64X)
90450-22M14-00
Unavailable
28
HOSE 1
5JW-1243A-00-00
Unavailable
29
CLIP(3BM)
90467-10135-00
Unavailable
30
HOSE 2
5JW-1243E-10-00
Unavailable
31
CLIP(3BM)
90467-10135-00
Unavailable
32
CLIP(3YX)
90467-13133-00
Unavailable
33
HOSE, 4
5JW-1244G-10-00
Unavailable
34
CLIP
90467-090A2-00
Unavailable
35
CLIP
90467-100A1-00
Unavailable
36
TANK, RECOVERY
5JW-21871-01-00
Unavailable
37
BOLT, WITH WASHER(55K)
90119-06117-00
Unavailable
38
BOLT, WITH WASHER (30X)
90119-06096-00
Unavailable
39
CAP
1AA-21815-00-00
Unavailable
40
GASKET
1AA-21874-00-00
Unavailable
41
HOSE (L840)
90445-09009-00
Unavailable
42
CLIP
90467-090A2-00
Unavailable
43
CLAMP(3LD)
90464-09129-00
Unavailable
44
CLAMP(56R)
90464-60067-00
Unavailable
45
CLAMP
90464-13249-00
Unavailable
46
BRACKET, RECOVERY TANK
5JW-21873-00-00
Unavailable
47
DAMPER
5DM-28371-00-00
Unavailable
48
COLLAR
90387-06107-00
Unavailable
