Yamaha FJR13ATC (FJR1300ABS CA) 5VSB 2005 COWLING 2 Diagram

#

Description
Price

1

BODY, FRONT LOWER 1 (DARK PURPLISH BLUE METALLIC L)

5VS-Y283J-40-P1

Unavailable

2

EMBLEM

5JW-28328-50-00

$62.99

3

DAMPER 1

5VS-2834E-00-00

Unavailable

4

. DAMPER

5JW-28371-00-00

Unavailable

5

NUT, SPRING

90183-051A0-00

$3.81

6

GROMMET

90480-13014-00

$8.49

7

NUT, SPRING

90183-051A0-00

$3.81

8

SCREW, TAPPING(4MV)

97707-50016-00

$2.19

9

FRONT FLASHER LIGHT ASSY 1

5VS-83310-00-00

Unavailable

10

BULB, FLASHER

5GJ-83331-00-00

$15.49

11

CORD ASSY

5GJ-8331E-00-00

Unavailable

12

. DAMPER 3

5JW-28237-00-00

Unavailable

13

BOLT

90111-05003-00

$8.49

14

PANEL, INNER 1

5JW-2836K-00-00

Unavailable

15

DAMPER 1

5JW-28217-00-00

Unavailable

16

SCREW, TRUSS TAP.

97707-40012-00

Unavailable

17

BOLT

90111-05003-00

$8.49

18

BOLT

90109-06037-00

Unavailable

19

RIVET(4JH)

90269-07076-00

Unavailable

20

BODY, FRONT LOWER 2 (DARK PURPLISH BLUE METALLIC L)

5VS-Y283K-40-P1

Unavailable

21

EMBLEM

5JW-28328-50-00

$62.99

22

. DAMPER 2

5VS-2174Y-00-00

Unavailable

23

DAMPER

5VS-2834F-00-00

Unavailable

24

. DAMPER

5JW-28371-00-00

Unavailable

25

NUT, SPRING

90183-051A0-00

$3.81

26

GROMMET

90480-13014-00

$8.49

27

NUT, SPRING

90183-051A0-00

$3.81

28

SCREW, TAPPING(4MV)

97707-50016-00

$2.19

29

. DAMPER 3

5JW-28237-00-00

Unavailable

30

FRONT FLASHER LIGHT ASSY 2

5VS-83320-00-00

Unavailable

31

BULB, FLASHER

5GJ-83331-00-00

$15.49

32

CORD ASSY

5GJ-8331E-00-00

Unavailable

33

PANEL, INNER 2

5JW-2836L-00-00

Unavailable

34

DAMPER 1

5JW-28217-00-00

Unavailable

35

SCREW, TRUSS TAP.

97707-40012-00

Unavailable

36

BOLT

90111-05003-00

$8.49

37

BOLT

90109-06037-00

Unavailable

38

RIVET(4JH)

90269-07076-00

Unavailable

39

COVER, LOWER

5JW-28385-10-P4

Unavailable

40

SEAT

5JW-2848H-00-00

Unavailable

41

SEAT 2

5JW-2848K-00-00

Unavailable

42

SEAT 3

5JW-2848L-00-00

Unavailable

43

MOLE 1

5JW-28345-00-00

Unavailable

44

SCREW, TAPPING(4MV)

97707-50016-00

$2.19

45

BOLT

90111-05003-00

$8.49

46

BRACKET 1

5JW-2836A-00-00

Unavailable

47

BRACKET 2

5JW-2836E-00-00

Unavailable

48

BOLT, WITH WASHER(55K)

90119-06117-00

Unavailable

49

NUT, SPRING

90183-051A0-00

$3.81

50

BRACKET 3

5JW-2836F-00-00

Unavailable

51

BOLT, FLANGE

95817-06012-00

Unavailable

52

WASHER, PLATE(1KT)

90202-05180-00

Unavailable

53

WIRE, SUB LEAD

5VS-82509-00-00

Unavailable
