Yamaha FJ600LC (FJ600 CA) 1984 REAR WHEEL Diagram

#

Description
Price

1

WHEEL, CAST REAR

33M-25338-20-98

Unavailable

2

BEARING(4HM)

93306-30317-00

$39.99

3

BEARING (10H)

93306-20314-00

$32.99

4

OIL SEAL (25X47X7-801)

93102-25044-00

$14.99

5

SPACER

90560-17241-00

Unavailable

6

FLANGE, SPACER

146-25315-00-00

$7.99

7

DAMPER

29L-25364-00-00

Unavailable

8

110/90-18 K130TL

94111-18486-00

Unavailable

8

120/90-18K727 DUN

94112-183N9-00

Unavailable

9

VALVE, RIM (31A)

93900-00031-00

$16.99

10

BALANCER, WHEEL

5MT-25398-00-00

$17.49

10

BALANCER, WHEEL

5MT-25398-10-00

$17.49

10

BALANCER, WHEEL

5MT-25398-20-00

Unavailable

11

CLUTCH, HUB

1JK-25366-00-00

Unavailable

12

BEARING(3BC)

93306-30437-00

$66.99

13

OIL SEAL (29L)

93102-32298-00

Unavailable

14

COLLAR

90387-172J8-00

Unavailable

15

SPROCKET, DRVN 45T (45T)

49A-25445-22-00

Unavailable

16

BOLT, HEXAGON SOCKET HEAD (29L

90110-08057-00

Unavailable

17

NUT, SELF-LOCKING

90185-08169-00

Unavailable

18

CHAIN 50HDS-106L

94580-63106-00

Unavailable

19

PULLER, CHAIN 1

12R-25388-00-00

Unavailable

20

PULLER,CHAIN 2

12R-25389-00-00

Unavailable

21

BOLT

90101-08060-00

Unavailable

22

. NUT

95380-08700-00

Unavailable

23

AXLE, WHEEL

12R-25381-00-00

Unavailable

24

NUT, CASTLE (4V7)

90171-14031-00

Unavailable

25

PIN, COTTER

91490-30030-00

Unavailable

26

COLLAR

90387-172J9-00

Unavailable
