Yamaha FJ1200AEC (FJ1200 CA) 1993 STAND FOOTREST Diagram

#

Description
Price

1

STAND, MAIN

36Y-27111-01-33

Unavailable

2

BOLT(1TX)

90109-101E6-00

$19.99

3

NUT, SELF LOCKING (3G1)

90185-10091-00

$9.49

4

SPRING, TENSION (12R)

90506-45278-00

Unavailable

5

STAND,SIDE

1TX-27311-00-R4

Unavailable

6

HOOK, SIDE STAND

36Y-27352-00-00

Unavailable

7

BOLT, HEXAGON

97017-08020-00

$9.49

8

WASHER, PLATE(J42)

90201-084K3-00

Unavailable

9

SPRING, TENSION(36Y)

90506-29358-00

$12.49

10

FRT FOOTREST ASSEMBLY LASSEMBLY (LEFT)

3CV-27410-00-00

Unavailable

11

COVER, FOOTREST

22N-27413-00-00

$48.99

12

BOLT

90109-08224-00

$2.55

13

NUT, SELF-LOCKING

95617-06100-00

$8.49

14

FRT FOOTREST ASSEMBLY RASSEMBLY (RIGHT)

3CV-27420-00-00

Unavailable

15

COVER, FOOTREST

22N-27413-00-00

$48.99

16

BOLT

90109-08224-00

$2.55

17

NUT, SELF-LOCKING

95617-06100-00

$8.49

18

BOLT(47X)

90109-082A1-00

Unavailable

19

WASHER(1UF)

90209-08295-00

Unavailable

20

BOLT

90109-086E4-00

Unavailable

21

BRACKET 2

3XW-27442-00-00

Unavailable

22

PLATE 1

3XW-27445-00-00

Unavailable

23

BRACKET 3

3XW-27443-00-00

Unavailable

24

PLATE 2

3XW-27446-00-00

Unavailable

25

DAMPER, FOOTREST

3XW-27414-00-00

Unavailable

26

BUSH, SPEC''L NYLON

90386-20130-00

Unavailable

27

BRACKET 4

3XW-2741L-00-00

Unavailable

28

SCREW,PAN HEAD (646)

98580-05012-00

Unavailable

29

YBS67-5 WASHER, SPRING

92990-05100-00

Unavailable

30

DAMPER, FOOTREST 2

36Y-27424-01-00

Unavailable

31

COLLAR

90387-10048-00

Unavailable

32

BOLT(47X)

90109-082A1-00

Unavailable

33

BOLT, HEXAGON SOCKET HEAD(53Y)

90110-08096-00

Unavailable

34

BOLT, BUTTON HEAD

92017-10040-00

Unavailable

35

NUT, SPEC''L SHAPE

90179-10276-00

Unavailable

36

WASHER, PLATE (2H7)

90201-10669-00

Unavailable

37

RR FOOTREST ASSEMBLY 1

29L-27430-00-00

Unavailable

38

. COVER, RR FOOTREST

22N-27433-00-00

Unavailable

39

SCREW, PAN HEAD(3LA)

98517-05010-00

Unavailable

40

RR FOOTREST ASSEMBLY 2

29L-27440-00-00

Unavailable

41

. COVER, RR FOOTREST

22N-27433-00-00

Unavailable

42

SCREW, PAN HEAD(3LA)

98517-05010-00

Unavailable

43

NUT, FLANGE(3BM)

95704-10500-00

Unavailable
