Description

Price

1

Black, Rear Bumper

204050278

Unavailable

2

Black, Rear Bumper Trim - Call your local BRP dealership

204050279

Unavailable

3

Pop Rivet 3/16"

293150014

$1.09

4

Tridon Gear Clamp

293650019

$5.82

5

Flexible Hose (Meter)

291000102

Unavailable

6

Pop Rivet 3/16"

293150043

$2.09

7

GASKET - Call your local BRP dealership This part replaces 293250251.

293250006

Unavailable

8

Fitting

293710162

$13.49

9

Drain Plug

292000187

$14.49

10

GASKET - Call your local BRP dealership

293250030

Unavailable

11

Cover

204000060

Unavailable

12

Pop Rivet 3/16"

293150039

$1.49

13

Loctite 271, 10 ml

293800005

$26.99

14

Flat Washer M5, Stainless

234051600

$0.77

15

PHILLIPS SCREW #10 X 7/8 - Call your local BRP dealership

211000021

Unavailable

16

Était Was 413705800 Loctite 414 , 29.5 c.c

219704463

$27.99

17

Hex. Nut M8

232081600

$1.47

18

Lock Washer 8 mm, Stainless

234181601

$0.55

19

RETAINING PLATE - Call your local BRP dealership

291000307

Unavailable

20

Finition Plate

291000544

Unavailable

21

Flat Washer M8.5 x 18

293050001

$3.07

22

U-CLAMP - Call your local BRP dealership

292000063

Unavailable

23

Silicone Sealant 51388, 300 ml

296000309

$36.99

Sea-doo Explorer, 5455, 2002 09- Body And Accessories 1 Diagram

Black, Rear Bumper

Black, Rear Bumper Trim - Call your local BRP dealership

Pop Rivet 3/16"

Tridon Gear Clamp

Flexible Hose (Meter)

Pop Rivet 3/16"

GASKET - Call your local BRP dealership This part replaces 293250251.

Fitting

Drain Plug

GASKET - Call your local BRP dealership

Cover

Pop Rivet 3/16"

Loctite 271, 10 ml

Flat Washer M5, Stainless

PHILLIPS SCREW #10 X 7/8 - Call your local BRP dealership

Était Was 413705800 Loctite 414 , 29.5 c.c

Hex. Nut M8

Lock Washer 8 mm, Stainless

RETAINING PLATE - Call your local BRP dealership

Finition Plate

Flat Washer M8.5 x 18

U-CLAMP - Call your local BRP dealership

Silicone Sealant 51388, 300 ml
