Description

Price

1

FAIRING

88R-77231-00-00

Unavailable

1

FAIRING 1

88S-77231-00-00

Unavailable

2

SCREW, WITH WASHER(35R)

90159-06093-00

$8.49

3

SRAY, FAIRING

88R-77241-00-00

Unavailable

4

BRACKET, WINDSHIELD (L.H)

88R-77221-00-00

Unavailable

5

SCREW, BINDING

98907-06008-00

$8.49

6

BOLT, HEXAGON

97017-06030-00

$3.61

7

WASHER, SPRING

92907-06100-00

$4.25

8

WINDSHIELD COMP.

88R-77210-00-00

Unavailable

9

SCREW, ROUND HEAD(88R)

90150-05028-00

$4.29

10

WASHER, PLATE 8067717800

90201-05029-00

$8.49

11

NUT, HEXAGON

95317-05600-00

$2.34

12

BRACKET, METER

82M-83519-01-00

Unavailable

13

SCREW, BINDING

98907-06008-00

$8.49

14

COVER, HEADLIGHT

88R-77251-00-00

Unavailable

15

SCREW, BINDING

98907-05016-00

Unavailable

16

STRIPE 1

88R-77281-00-00

Unavailable

17

EMBLEM 16

89F-77372-00-00

Unavailable

17

EMBLEM 16

89K-77372-00-00

Unavailable

18

INDICATOR, COCK

86M-24153-00-00

Unavailable

19

CAUTION LABEL 1

80V-2835Y-90-00

Unavailable

Yamaha EX570ES (EXCITER II LE (ELEC START)) 1992 WINDSHIELD Diagram

FAIRING

FAIRING 1

SCREW, WITH WASHER(35R)

SRAY, FAIRING

BRACKET, WINDSHIELD (L.H)

SCREW, BINDING

BOLT, HEXAGON

WASHER, SPRING

WINDSHIELD COMP.

SCREW, ROUND HEAD(88R)

WASHER, PLATE 8067717800

NUT, HEXAGON

BRACKET, METER

SCREW, BINDING

COVER, HEADLIGHT

SCREW, BINDING

STRIPE 1

EMBLEM 16

EMBLEM 16

INDICATOR, COCK

CAUTION LABEL 1
