Yamaha EX1050CS (EX) F3Y5 2017 EXHAUST 2 Diagram

#

Description
Price

1

HOSE 2

6GA-E243E-00-00

$14.38

2

TUBE (L410)

90447-22015-00

$6.36

3

JOINT ASSY

6EY-12580-00-00

$49.49

4

CLIP

90467-150A5-00

$2.64

5

HOSE (L420)

90446-24M89-00

$9.08

6

CAP,1

682-84385-01-00

$9.08

7

NUT

EU0-61652-00-00

$11.48

8

CLIP

90467-200A3-00

$5.92

9

JOINT, HOSE 3

6EY-12584-00-00

$12.86

10

HOSE (L400)

90445-18012-00

$24.98

11

TUBE (L300)

90447-19014-00

$5.14

12

CLIP

90467-160A0-00

$2.95

13

CLAMP

90465-13M18-00

$1.71

14

HOSE (L170)

90445-21015-00

$13.99

15

CLIP

90467-200A3-00

$5.92

16

HOSE (L160)

90445-16019-00

$7.27

17

HOSE (L70)

90446-24M44-00

$3.64

18

. CLIP

90467-150A1-00

$3.33

19

HOSE (L1600)

90445-16020-00

$24.23

20

TUBE

6EY-24864-00-00

$10.49

21

CLIP

90467-160A0-00

$2.95

22

HOSE 2

6EY-12577-00-00

$14.38

23

CLIP

90467-160A0-00

$2.95

24

HOSE 4

6S5-12579-00-00

$14.44

25

CLIP

90467-160A0-00

$2.95

26

HOSE (L370)

90445-18018-00

$16.99

27

CLIP

90467-160A0-00

$2.95

28

THERMOSTAT

6D3-12411-00-00

$95.40

29

COVER, THERMOSTAT

6EY-12413-00-00

$15.49

30

BOLT, FLANGE

90105-06035-00

$2.27

31

HOSE 1

F5P-E243A-00-00

Unavailable

32

TUBE (L490)

90447-28012-00

$12.86

33

CLIP

90467-240A0-00

$6.82

34

CONDUCTION ASSY (US)

67X-E2590-00-00

$2.08

35

CLIP

90467-200A0-00

$7.40

36

CLIP

90467-26800-00

$2.66
