Description

Price

1

FRAME

8W9-21910-00-00

Unavailable

2

HOOD 1

82A-21982-00-00

Unavailable

3

HOOD 2

8Y3-21983-70-00

Unavailable

4

RIVET, BLIND (8H4)

90267-48053-00

$3.61

5

RIVET, BLIND (8J5)

90267-48057-00

$8.49

6

WASHER

90201-04015-00

Unavailable

7

WASHER, PLATE (8M6)

90201-047A2-00

$3.35

8

BODY, LATCH 1

8M6-77171-00-00

Unavailable

9

COLLAR (420)

90387-06241-00

$8.49

10

WASHER, PLATE 8221447500

90201-06057-00

$5.60

11

SCREW, BINDING

98907-06025-00

$8.49

12

EMBLEM 4

8W9-77354-00-00

Unavailable

13

EMBLEM 5

8W9-77355-00-00

Unavailable

14

COVER,1

85T-2198F-00-00

Unavailable

15

SCREW, BINDING

98907-06012-00

$9.49

16

NUT, FLANGE(7NB)

95780-06500-00

Unavailable

17

ORNAMENT 3

8W9-77169-00-00

Unavailable

18

ORNAMENT 4

8W9-77113-00-00

Unavailable

19

EMBLEM 8

8W9-77358-00-00

Unavailable

20

EMBLEM 9

8W9-77359-00-00

Unavailable

Yamaha ET340H (ENTICER 340) 1984 FRAME Diagram

FRAME

HOOD 1

HOOD 2

RIVET, BLIND (8H4)

RIVET, BLIND (8J5)

WASHER

WASHER, PLATE (8M6)

BODY, LATCH 1

COLLAR (420)

WASHER, PLATE 8221447500

SCREW, BINDING

EMBLEM 4

EMBLEM 5

COVER,1

SCREW, BINDING

NUT, FLANGE(7NB)

ORNAMENT 3

ORNAMENT 4

EMBLEM 8

EMBLEM 9
