Yamaha ET250C 1979 INSTRUMENT PANEL ET250D Diagram

#

Description
Price

1

PANEL, INSTRUMENT

8G5-77711-00-00

Unavailable

2

PANEL, INSTRUMENT

8F3-77712-00-00

Unavailable

3

HINGE 1

8F3-77726-01-00

Unavailable

4

HINGE 2

8F3-77727-00-00

Unavailable

5

SCREW,PAN HEAD (646)

98580-05012-00

$7.99

6

WASHER, PLAIN (646)

92990-05600-00

$0.80

7

YBS67-5 WASHER, SPRING

92990-05100-00

$0.35

8

NUT, HEXAGON (663)

95380-05600-00

$8.49

9

SPRING, TENSION

90506-10090-00

Unavailable

10

DAMPER 1

(811-77461-00-00)

Unavailable

11

LABEL, WARNING 6

8F3-77766-00-00

Unavailable

12

INDICATOR 3

8A1-77743-00-00

Unavailable

13

INDICATOR 4

878-77744-00-00

Unavailable

14

INDICATOR 4

8A1-77744-00-00

Unavailable

15

INDICATOR 1

8J5-77741-00-00

Unavailable

16

LABEL, WARNING 7

8L2-77767-00-00

Unavailable

17

SCREW, PAN

98507-06014-00

Unavailable

18

WASHER, PLATE 8221447500

90201-06057-00

Unavailable

19

WASHER, SPRING

92907-06100-00

Unavailable

20

GROMMET

8F3-77746-00-00

Unavailable
