Ski-Doo Elite 1500 2nd Edition, 2004 05- Drive System 2 Diagram

#

Description
Price

1

Gear 38 Teeth

504152285

Unavailable

2

Washer

512059991

Unavailable

3

Washer 10 mm

506150000

$2.74

4

HEX. SCREW M10 X 40, SCOTCH GRIP - Call your local BRP dealership

245004060

Unavailable

5

LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership

219704461

Unavailable

6

FILLER CAP ASSY - Call your local BRP dealership

504151750

Unavailable

7

O-RING - Call your local BRP dealership

414969400

Unavailable

8

SYNTHETIC CHAINCASE OIL, 12 X 355 ML - Call your local BRP dealership

413803300

Unavailable

9

Transmission Support

504152166

Unavailable

10

Hex. Forming Screw M8 X 25

210282540

Unavailable

11

Hex. Screw With Nylon

250000118

Unavailable

12

Yellow, Washer

503183200

$3.19

13

Rear Extrusion

504152227

Unavailable

14

Fixation Plate

518323288

Unavailable

15

Pop Rivet 3/16"

390402200

$0.35

16

Front Extrusion

504152228

Unavailable

17

Hex. Flange Elastic Nut M8

233281414

$1.47

18

Battery Support

504152229

Unavailable

19

LOWER BATTERY PAD - Call your local BRP dealership

278001582

Unavailable

20

Battery Attach

504152350

Unavailable

21

Anchor Rod

504152351

Unavailable

22

Elastic Stop Nut M6

232561414

$0.55

23

Flat Washer 6 mm

234062410

$0.77

24

Hex. Flange Screw M8 X 20

207682044

$1.15

25

Hex. Flange Elastic Nut M8

233281414

$1.47

26

Hex. Screw M10 X 12

230102044

Unavailable

27

Hex. Nut M10 X 1.5

232006414

$1.37

28

Hex. Jam Nut M10

232100600

$2.22

29

Pivot

504152230

Unavailable

30

Pivot Plate

504152243

Unavailable

31

Shifting Rod

504152242

Unavailable

32

Spring

504152281

Unavailable

33

Hex. Flange Screw M6 X 25

207662544

$0.64

34

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47

35

CUSHION - Call your local BRP dealership

520000234

Unavailable

36

Tightening Bushing

504152332

Unavailable

37

Hex. Flange Screw M6 X 35

207663544

$0.90

38

LH BALL JOINT - Call your local BRP dealership

506151729

Unavailable

39

Hex. Jam Nut M8

232180600

$0.67

40

Ball Joint Support

504152330

Unavailable

41

SLIDING BLOCK - Call your local BRP dealership

505070817

Unavailable

42

BALL JOINT - Call your local BRP dealership

505070819

Unavailable

43

Lever

504152510

Unavailable

44

Pressure Screw M8 X 30

206583044

Unavailable

45

LEVER BUTTON - Call your local BRP dealership

705500022

Unavailable

46

Loctite 271, 10 ml

293800005

$26.99

47

SOCKET HEAD SCREW M6 X 16 - Call your local BRP dealership

250000172

Unavailable

48

Insert

293450275

$12.99

49

HEX. FLANGED SCREW M5 X 11 - Call your local BRP dealership

210251180

Unavailable

50

Hex. Flange Screw M6 X 35

207663544

$0.90

51

Hex. Flange Elastic Nut M6 x 1.0

233261414

$1.47
