Ski-Doo Elite 1500 2nd Edition, 2004 02- Oil Separator Diagram

#

Description
Price

1

OIL PUMP HOUSING - Call your local BRP dealership

420811840

Unavailable

2

PUMP SHAFT ASS'Y - Call your local BRP dealership

420837542

Unavailable

3

Oil Pump Rotor 16 mm

420956675

$36.99

4

Oil Pump Cover

420811851

$33.99

5

Torx Flange Screw M6 X 16

420641048

$2.96

6

Gasket

420950970

$12.64

7

Torx Flange Screw M6 X 25

420641238

$3.27

8

OIL SIEVE COVER - Call your local BRP dealership

420811892

Unavailable

9

SEAL RING - Call your local BRP dealership

420630240

Unavailable

10

GASKET - Call your local BRP dealership

420950850

Unavailable

11

OIL SIEVE - Call your local BRP dealership

420256570

Unavailable

12

Torx Flange Screw M6 X 85

420641228

$7.41

13

Torx Flange Screw M6 X 25

420641238

$3.27

14

Torx Flange Screw M6 X 25

420641238

$3.27

15

Plug Screw M10 X 1

420641323

$14.28

16

GASKET - Call your local BRP dealership

420630231

Unavailable

17

OIL SEPARATOR HOUSING - Call your local BRP dealership

420956761

Unavailable

18

Interr.Pression*Oil Tk Pres Sw This part replaces 420256885.

420256886

$51.99

19

OIL SEPARATOR COVER - Call your local BRP dealership

420811962

Unavailable

20

Plug Screw M20 X 1.5

420641317

$14.22

21

Gasket

420630540

Unavailable

22

GASKET - Call your local BRP dealership

420630220

Unavailable

23

Torx Flange Screw M6 X 25

420641238

$3.27

24

Plug Cover, Yellow

420956923

$23.49

25

Retaining Band

420660620

$7.41

26

Rubber Bracket

420660090

$4.12

27

SPACER - Call your local BRP dealership

420847970

Unavailable

28

Flat Washer M6

420827968

$1.90

29

Torx Flange Screw M6 X 35

420641258

$3.38

30

FRONT TRANSPORT BRACKET - Call your local BRP dealership

420851610

Unavailable

31

Torx Flange Screw M6 X 16

420641048

$2.96

32

Formed Hose

420956970

Unavailable

33

Gear Clamp

420851673

$5.71

34

Oeticker Gear Clamp, 25.6-706R

509000442

$5.19

35

Loctite 243, 10 ml

293800060

$21.49

36

Synth Oil 4T 12x1

293600054

Unavailable
