Ski-Doo Elite 1500 1st Edition, 2004 08- Front arm Diagram

#

Description
Price

1

Hex. Flange Elastic Nut M8

233281414

$1.47

2

Hex. Screw M8 X 25

207182544

$0.90

3

Flat Washer 12 mm

234021410

$0.72

4

Front Arm

503189292

Unavailable

5

Washer

503189276

$3.28

6

HEX. SCREW M12 X 60, SCOTCH GRIP - Call your local BRP dealership

207226044

Unavailable

7

Hex. Screw M12 X 120, Scotch Grip

230222044

Unavailable

8

SHAFT - Call your local BRP dealership

503189313

Unavailable

9

CUSHION - Call your local BRP dealership

503189323

Unavailable

10

Center Shock

503190542

Unavailable

11

Adjustment Cam

505073625

$12.99

12

Spring

503190543

Unavailable

13

Protector

503193663

$37.99

14

Spring Guide

503191872

$2.29

15

Spring Stopper

706200881

$12.99

16

Urethane Bushing

503189117

$8.19

17

Bushing | Includes 240d to 240d1

503189282

$4.34

18

Bushing

503189271

$13.99

19

LH Shock Spacer | LH Rear suspension

503190545

Unavailable

20

Hex. Screw M10 X 1.5 X 50

207005044

$3.80

21

Elastic Locking Nut M10 X 1.5

233601416

$1.69

22

AXLE - Call your local BRP dealership

503189562

Unavailable

23

Socket Head Screw M10 X 35, Scotch Grip

205503544

$1.69

24

Washer

503189564

$0.74

25

Stopper Strap, Large

503190563

Unavailable

26

Spacer

503189265

$4.99

27

Flat Washer

224081301

$0.88

28

Hex. Elastic Stop Nut M8

232581414

$0.56

29

Socket Head Screw M12 X 35, Scotch Grip

205523544

$2.96

30

CENTER SHOCK SHAFT - Call your local BRP dealership This part replaces 503191258.

503189272

Unavailable

31

Washer

503189273

$3.28

32

SPACER - Call your local BRP dealership

503189274

Unavailable

33

Rocker

503189845

Unavailable

34

Rocker Axle

503189388

Unavailable

35

CUSHION - Call your local BRP dealership

503189626

Unavailable

36

Rear Shock

503189426

Unavailable

37

Hex. Flange Screw M8 X 40

207684044

$1.48

38

Bushing

414936000

$13.99

39

Grease Fitting

408200700

$3.49

40

SYNTHETIC GREASE, 400 G - Call your local BRP dealership

219700417

Unavailable

41

Bushing

503190537

Unavailable

42

Cushion

572032600

Unavailable

43

Support Bushing

503190528

Unavailable
