Description

Price

315

NUT-HEX-FINE,10MM

315AA1000

$0.59

411

WASHER-PLAIN,12MM

411AA1200

$0.96

550

PIN-COTTER,3.0X25

550AA3025

$0.62

601

BEARING-BALL,#6201UG

601B6201UG

$19.40

41035

PANEL-ASSY-BRAKE,RR,BLACK

41035-0085-10

$268.85

41048

SHOE-BRAKE

41048-0008

$10.02

41050

CAM-BRAKE

41050-1098

$8.74

41051

SEAL,BRAKE CAM

41051-001

$4.26

41053

LEVER-BRAKE CAM

41053-1089

$5.92

41068

AXLE

41068-0082

$9.87

41073

WHEEL-ASSY,RR,G.BLACK

41073-0570-21V

$356.86

41085

INDICATOR

41085-1079

$0.84

42033

COUPLING-ASSY,RR HUB

42033-0024

$53.01

42036

SLEEVE,RR HUB COUPLING,L=29

42036-0041

$8.89

42041

SPROCKET-HUB,38T

42041-0112

$71.18

92015

NUT,FLANGED,6MM

92015-1367

$3.69

92015A

NUT,CASTLE,12MM

92015-1870

$6.36

92022

WASHER,LOCK

92022-1705

$7.68

92045

BEARING-BALL,#6301DUC3E

92045-0714

$15.08

92045A

BEARING-BALL,#6004UG

92045-0717

$21.95

92049

SEAL-OIL,S 26 42 8

92049-1428

$22.81

92057

CHAIN,DRIVE,RK420SBX104L

92057-0162

$44.44

92058

JOINT-CHAIN,DRIVE

92058-0020

$6.76

92144

SPRING,BRAKE SHOE

92144-1907

$4.61

92151

BOLT,FLANGED,6X34

92151-1209

$3.71

92152

COLLAR,RR BRAKE DRUM,L=58

92152-0354

$12.67

92152A

COLLAR,RR AXLE,LH,L=17

92152-0452

$17.24

92152B

COLLAR,12.2X24X25

92152-0806

$6.63

92154

BOLT,10X36

92154-0770

$3.53

92160

DAMPER,SHOCK,RR HUB

92160-1627

$11.91

Kawasaki EDGE VR Rear Hub(SCF) Diagram
