1988 Yamaha DT50W (DT50LC) Tachometer Diagram

← All diagrams

Find the part on the Tachometer diagram for your 1988 Yamaha DT50W (DT50LC), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1988 Yamaha DT50W (DT50LC) Tachometer Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GEAR, DRIVEN

5R2-17841-00-00

1
Out of stock

2

WASHER (692)

90201-12M34-00

1
Out of stock

3

OIL SEAL (30X)

93102-08307-00

1
Out of stock

4

O-RING (26H)

93210-14579-00

1
Out of stock

5

SCREW, PAN HEAD(6E0)

97885-06030-00

1
Out of stock
← Starter Tachometer Gear →
