Yamaha DT50LC (DT50W) 1988 FRONT WHEEL Diagram

#

Description
Price

1

HUB, FRONT

248-25111-00-98

Unavailable

2

BEARING

93306-30102-00

$39.99

3

SPACER

90560-12138-00

Unavailable

4

FLANGE, SPACER

109-25315-00-00

$7.99

5

OIL SEAL (18X37X8-109)

93102-18008-00

$25.99

6

PLATE, BRAKE SHOE

4J8-25121-00-98

Unavailable

7

BRAKESHOE SET-2PCS

18A-W2534-00-00

Unavailable

8

SPRING, TENSION (18A)

90506-18288-00

$8.49

9

INACTIVE PART NUMBER

2J7-25135-00-00

Unavailable

10

BUSHING

109-25136-00-00

$10.99

11

GEAR, METER

2J7-25138-00-00

Unavailable

12

OIL SEAL (7X14X4-136)

93104-07003-00

$8.49

13

WASHER, PLATE 1832514600

90201-07076-00

$7.49

14

WASHER, PLATE 1832514700

90201-20269-00

$7.49

15

CLUTCH, METER

183-25149-00-00

$6.99

16

CIRCLIP(1AR)

99009-20400-00

Unavailable

17

LEVER, CAM SHAFT

2N3-25155-00-00

Unavailable

18

BOLT, HEXAGON (538)

90101-06278-00

Unavailable

19

NUT, HEXAGON

95380-06600-00

Unavailable

20

CAMSHAFT

4GL-25351-00-00

Unavailable

21

SEAL,OIL

93105-47007-00

Unavailable

22

PLATE

3Y6-2533A-01-00

Unavailable

23

SPOKE SET, FRONT

17W-25104-00-00

Unavailable

24

IRC 250-19 GP1

94125-192T8-00

Unavailable

25

TUBE (2.75-19)(3GX)

94227-19292-00

Unavailable

26

BAND, RIM

94327-19111-00

Unavailable

27

RIM (1.40-19)

94414-19003-00

Unavailable

28

COVER HUB DUST

481-25118-01-00

Unavailable

29

SHAFT, WHEEL (462)

90102-12015-00

Unavailable

30

WASHER, PLATE

90201-12047-00

Unavailable

31

NUT,CASTLE

90171-12058-00

Unavailable

32

PIN, COTTER

91490-30030-00

Unavailable

33

COLLAR

90387-12616-00

Unavailable

34

RING, STOP

102-25137-00-00

Unavailable

35

O-RING (26H)

93210-14579-00

Unavailable
