Yamaha DT360A (DT360A) 1974 FRONT WHEEL Diagram

#

Description
Price

1

HUB, FRONT

227-25111-00-00

Unavailable

2

SPOKE SET, FRONT

438-25104-00-00

Unavailable

3

RIM 1.60X21

94416-21038-00

Unavailable

4

TIRE 300X21 DUN TRIUNI

94130-21316-00

Unavailable

5

TUBE (80/100-21 M/C TR4)

94203-21316-00

Unavailable

6

BAND, RIM

94327-21024-00

Unavailable

7

SPACER, BEAD

1T1-25194-00-00

Unavailable

8

SPACER(1EE)

90560-15293-00

Unavailable

9

FLANGE, SPACER

146-25116-00-00

$8.99

10

BRG, R-B (7H4)

93306-20211-00

$25.99

11

OIL SEAL (20X35X7-136)

93102-20009-00

$10.49

12

BRG,R-B 6202Z 35MM 48G NT

93306-20204-00

$22.99

13

CIRCLIP(1EY)

99009-22400-00

$8.49

14

WASHER PLATE 214251470000

90201-22283-00

$5.60

15

CLUTCH, METER

214-25149-01-00

$7.99

16

GEAR, DRIVE

308-25135-00-00

Unavailable

17

PLATE, BRAKE SHOE

438-25120-10-00

Unavailable

18

CAMSHAFT

214-25151-00-00

Unavailable

19

WASHER PLATE 341251470000

90201-25286-00

Unavailable

20

OIL SEAL (50X62X7-214)

93105-50010-00

Unavailable

21

BRAKE SHOE KIT

3GW-W253A-00-00

Unavailable

22

SPRING, TENSION 2462533300

90507-20002-00

Unavailable

23

LEVER, CAMSHAFT 1

214-25155-01-00

Unavailable

24

BOLT(JF7)

97080-06030-00

Unavailable

25

NUT

95303-03600-00

Unavailable

26

WASHER, SPRING

92995-06100-00

Unavailable

27

YBS66-6 WASHER, PLAIN

92990-06200-00

Unavailable

28

GEAR, METER

308-25138-00-00

Unavailable

29

WASHER, PLATE 1832514600

90201-07076-00

Unavailable

30

O-RING (26H)

93210-14579-00

Unavailable

31

BUSHING

109-25136-00-00

Unavailable

32

OIL SEAL (7X14X4-136)

93104-07003-00

Unavailable

33

RING, STOP

102-25137-00-00

Unavailable

34

AXLE, WHEEL

275-25181-00-00

Unavailable

35

COLLAR

90387-15117-00

Unavailable

36

COVER, HUB DUST

1R0-25118-00-00

Unavailable

37

COLLAR

90387-157G5-00

Unavailable

38

WASHER, PLAIN

92990-14200-00

Unavailable

39

NUT, CASTLE(2UJ)

90171-14056-00

Unavailable

40

PIN, COTTER

91490-30030-00

Unavailable
