Yamaha DT125A (DT125A) 1974 ELECTRICAL Diagram

#

Description

Price

1

WIRE HARNESS ASSEMBLY

(444-82590-10-00)

Unavailable

1

WIRE HARNESS ASSEMBLY

(444-82590-11-00)

Unavailable

2

COVER, CONNECTER

(444-82599-00-00)

Unavailable

3

BAND, SWITCH CORD

437-83936-01-00

$7.99

4

MAIN SWITCH ASSEMBLY

(444-82508-11-00)

Unavailable

4

MAIN SWITCH ASSEMBLY

(444-82508-12-00)

Unavailable

5

. DAMPER, MAIN SWITCH

437-82555-00-00

Unavailable

6

DAMPER, STOPPER

1M1-82556-00-00

Unavailable

7

COLLAR, MAIN SWITCH

437-82516-00-00

Unavailable

8

SCREW, PAN HEAD

98580-05020-00

Unavailable

9

YBS67-5 WASHER, SPRING

92990-05100-00

$0.35

10

. WASHER, PLAIN

92990-05200-00

Unavailable

11

IGNITION COIL ASSEMBLY

254-82310-60-00

Unavailable

12

BRACKET, IGN COIL

(248-82316-00-00)

Unavailable

13

WASHER, SPRING

92995-06100-00

Unavailable

14

NUT, HEXAGON

95380-06600-00

Unavailable

15

SCREW, PAN HEAD(62J)

97885-06012-00

Unavailable

16

WASHER, SPRING

92995-06100-00

Unavailable

17

CORD, HIGHT TENSION 1

137-82341-01-00

Unavailable

18

PLUG CAP ASSY

56J-82370-00-00

Unavailable

19

HORN

444-83371-21-00

Unavailable

20

BOLT (661)

97013-06012-00

Unavailable

21

WASHER, SPRING

92995-06100-00

Unavailable

22

STOP SWITCH ASSEMBLY

248-82530-02-00

Unavailable

23

NEUTRAL SWITCH ASSY

136-82540-03-00

Unavailable

24

12N73BY YUASA BATTERY

12N-73BY0-00-00

Unavailable

25

BAND, BATTERY

261-82131-00-00

Unavailable

26

BAND, BATTERY

1UA-82124-00-00

Unavailable

27

SEAT, BATTERY

(173-82122-00-00)

Unavailable

28

HOSE

90445-08719-00

Unavailable

29

WIRE, PLUS LEAD

(261-82115-01-00)

Unavailable

30

FUSE HOLDER ASSY

2UJ-82150-02-00

Unavailable

31

FUSE

1A0-82161-00-00

Unavailable

32

PIN, COTTER

91490-40045-00

Unavailable

33

WIRE, MINUS LEAD

(261-82116-01-00)

Unavailable

34

VOLTAGE REG ASSEMBLY

444-81910-10-00

Unavailable

35

PLATE, REG FITTING

(444-81915-00-00)

Unavailable

36

SCREW, PAN

98507-06014-00

Unavailable

37

WASHER, SPRING

92995-06100-00

Unavailable

38

SCREW, PAN HEAD(62J)

97885-06012-00

Unavailable

39

WASHER, SPRING

92995-06100-00

Unavailable

40

WASHER, PLATE (371)

90201-06431-00

Unavailable

41

. STARTER RELAY ASSY

8J9-81940-10-00

Unavailable

42

SCREW, PAN HEAD(62J)

97885-06012-00

Unavailable

43

WASHER, SPRING

92995-06100-00

Unavailable

44

YBS66-6 WASHER, PLAIN

92990-06200-00

Unavailable

45

FLASHER RELAY ASSEMBLY

444-83350-71-00

Unavailable

46

WASHER, SPRING

92995-06100-00

Unavailable

47

NUT, HEXAGON

95380-06600-00

Unavailable
