Suzuki DS80 (2000) WIRING HARNESS Diagram

#

Description
Price

1

WIRING HARNESS

36610-03411

$70.70

2

CLAMP (L:95)

09407-11401

$2.63

2

CLAMP This part replaces 09407-18403.

09407-18402

$2.19

3

CLAMP (L:128)

09407-12402

$3.04

4

SWITCH ASSY, ENGINE STOP

37820-14X50

$48.54

5

BOOT

36618-44200

Unavailable

6

LABEL, ENGINE STOP | MODEL T/V/W This part replaces 37238-46400.

37238-46401

Unavailable

6

LABEL, STOP SWITCH | MODEL X/Y

37238-46401

Unavailable

6

LABEL, STOP SWITCH | MODEL T/V/W E28

37238-46410

Unavailable

6

LABEL, STOP SWITCH | MODEL X/Y E28

37238-46411

Unavailable

7

REFLECTOR, FRONT SIDE | E28

35950-30910

$30.05

8

WASHER, FRONT | E28 This part replaces 08322-01053.

08322-0105A

$1.84

9

REFLECTOR,REAR SIDE | E28

35970-30910

$44.56

10

BRACKET, REAR SIDE REFLECTOR | E28

35976-03430

Unavailable

11

NUT | E28 This part replaces 08316-20053.

08316-2005A

$2.19

12

REFLECTOR, REAR | E28

35970-30910

$44.56

13

NUT | E28 This part replaces 08316-20053.

08316-2005A

$2.19

14

BRACKET, REAR REFLECTOR | E28

35974-03430

Unavailable

15

SCREW | E28 This part replaces 02142-05103.

02142-0510B

$1.78

16

NUT | E28 This part replaces 08316-20053.

08316-2005A

$2.19
