FRONT FORK & FRONT FENDER
Yamaha DS6C (DS6C) 1969 FRONT FORK & FRONT FENDER Diagram
#
1
FRONT FORK ASSEMBLY
(246-23100-60-63)
Unavailable
1
TUBE, OUTER 1
(246-23126-00-93)
Unavailable
1
FRONT FORK ASSEMBLY
(247-23100-60-64)
Unavailable
1
FRONT FORK ASSEMBLY
(247-23100-60-65)
Unavailable
2
TUBE, OUTER 2
(246-23136-00-93)
Unavailable
3
TUBE, INNER 1
(246-23124-00-00)
Unavailable
4
. O-RING
156-23147-00-00
Unavailable
5
METAL, SLIDE 1
(171-23125-01-00)
Unavailable
6
NUT, OUTER TUBE
(204-23127-40-00)
Unavailable
7
OIL SEAL
2K5-23145-00-00
Unavailable
8
SEAT, SPRING LOWER
(156-23143-00-00)
Unavailable
9
SPRING, FRONT FORK
(246-23141-00-00)
Unavailable
10
. BOOT, FRONT FORK
211-23191-40-00
Unavailable
11
SEAT, SPRING UPPER
(171-23142-01-00)
Unavailable
11
SEAT, SPRING UPPER
(204-23142-40-00)
Unavailable
12
WASHER, OIL SEAL
(156-23146-00-00)
Unavailable
13
COVER, OUTER 1
(247-23122-60-00)
Unavailable
14
COVER, OUTER 2
(247-23132-60-00)
Unavailable
15
GASKET
(171-23163-01-00)
Unavailable
16
GUIDE, COVER LOWER
(171-23116-01-00)
Unavailable
17
COVER, UPPER 1
(246-23121-00-63)
Unavailable
17
COVER, UPPER 1
(246-23121-00-63)
Unavailable
17
COVER, UPPER 1
(246-23121-00-64)
Unavailable
18
COVER, UPPER 2
(246-23131-00-63)
Unavailable
18
COVER, UPPER 2
(246-23131-00-64)
Unavailable
18
COVER, UPPER 2
(246-23131-00-N7)
Unavailable
19
GASKET
(156-23114-00-00)
Unavailable
20
WASHER, CAP
(246-23112-00-00)
Unavailable
21
BOLT, CAP
(156-23111-01-00)
Unavailable
22
UNDER BRACKET
(246-23340-00-33)
Unavailable
23
HOLDER, CABLE 1
(183-23318-00-00)
Unavailable
24
YBS67-10 WASHER, SPRING
92990-10100-00
Unavailable
25
BOLT 1
122-23346-02-00
Unavailable
26
BOLT, HEXAGON
97013-08030-00
Unavailable
27
YBS67-8 WASHER, SPRING
92990-08100-00
Unavailable
28
SCREW, PAN HEAD (713)
98580-04008-00
Unavailable
29
GASKET, DRAIN PLUG
122-23129-00-00
Unavailable
30
RACE, BALL 1
B6E-23411-00-00
Unavailable
31
BALL
93501-04011-00
Unavailable
32
RACE, BALL 2
B6E-23412-00-00
Unavailable
33
RACE, BALL 1
4FP-F3411-20-00
Unavailable
34
RACE,BALL 2
4FP-F3412-10-00
Unavailable
35
COVER, BALL RACE
136-23415-00-00
Unavailable
36
NUT
90179-25004-00
Unavailable
37
CROWN, HANDLE
(246-23435-00-00)
Unavailable
38
WASHER, SPEC''L SHAP
90209-17057-00
Unavailable
39
NUT (95301-16600)
95303-16600-00
Unavailable
40
SPRING
(246-23428-00-00)
Unavailable
41
WASHER, PLATE 1412342700
90202-06008-00
Unavailable
42
WASHER, PLATE
90201-06061-00
Unavailable
43
SHAFT, DAMPER
(183-23419-00-00)
Unavailable
44
PLATE, DAMPER 1
(169-23421-00-33)
Unavailable
45
PLATE, DAMPER 2
(169-23422-01-00)
Unavailable
46
PLATE, DAMPER 3
(246-23423-00-00)
Unavailable
47
BOLT(62E)
97013-08012-00
Unavailable
48
YBS67-8 WASHER, SPRING
92990-08100-00
Unavailable
49
CLIP (156-83525-00)
90468-10050-00
Unavailable
50
HOLDER, HANDLE UPR
(168-23441-00-00)
Unavailable
51
BOLT
97013-08035-00
Unavailable
52
YBS67-8 WASHER, SPRING
92990-08100-00
Unavailable
53
BOLT, HEXAGON
97013-08055-00
Unavailable
54
YBS67-8 WASHER, SPRING
92990-08100-00
Unavailable
55
NUT(6L2)
95333-08600-00
Unavailable
56
STEERING LOCK ASSEMBLY
(156-23480-00-00)
Unavailable
57
RIVET
(122-23483-00-00)
Unavailable
58
FENDER, FRONT
(235-21510-00-00)
Unavailable
59
STAY, FENDER 1
(235-21513-00-00)
Unavailable
60
BOLT(3JP)
97017-06010-00
Unavailable
61
NUT, HEXAGON
95380-06600-00
Unavailable
62
WASHER, SPRING
92995-06100-00
Unavailable
63
HOLDER, CABLE
(152-21518-00-00)
Unavailable
64
BOLT(62E)
97013-08012-00
Unavailable
65
YBS67-8 WASHER, SPRING
92990-08100-00
Unavailable
66
DAMPER 2
5A8-21639-00-00
Unavailable
67
REFLECTOR, FRONT 1
(233-85111-00-00)
Unavailable
68
YBS67-5 WASHER, SPRING
92990-05100-00
Unavailable
69
. WASHER, PLAIN
92990-05200-00
Unavailable
70
COVER, LOWER 1
(246-23123-60-63)
Unavailable
71
COVER, LOWER 2
(246-23133-60-63)
Unavailable
72
OUTER NUT
(246-23150-00-00)
Unavailable
73
CLAMP, CABLE
(169-21337-00-00)
Unavailable
