Description

Price

1

Tail Light Ass'y

S33700RCB000

$91.76

1a

Tail Light Bulb

S34906RCA000

$12.43

2

Rear Frame

S50180RCB000

$649.99

3

Rubber Washer

S80103X01000

$4.09

4

Fender Collar

S80104X01000

$4.15

5

Flanged Nut 6 mm

S9405006070

$0.43

6

CVT Tube Stay

S50175RCA000

$12.79

7

Flanged Bolt M8 X 12

S958010801207

$0.72

8

Flanged Bolt M8 X 18

S958010801807

$0.72

11

Brake Pedal Spring

S50706RCA000

$5.04

12

Brake Switch Spring

S50707RCA000

$7.18

13

Brake Pedal Ass'y

S50708RCA000

$55.94

14

Brake Plate Washer

S50709RCA000

$3.29

15

E-Ring

S9454005017

$1.03

16

Pin

S91510RCA000

$5.10

17

Circlip 5 mm

293370002
