Suzuki DR650S (1993) REAR CALIPER Diagram

#

Description
Price

1

CALIPER ASSY, REAR

69100-12D01

Unavailable

1

PISTON SET This part replaces 69100-44850.

69100-44851

Unavailable

2

SEAL,PISTON This part replaces 59107-04A00.

59107-40F00

$10.95

3

SEAL, WIPER

59108-04A00

$10.77

4

PAD SET

69100-12810

Unavailable

5

SPRING

69115-44B00

Unavailable

6

GUIDE, PAD

69116-44B00

Unavailable

7

.PIN, PAD This part replaces 69141-44B01.

69141-44B02

$12.48

8

.CLIP, PAD PIN

69142-45000

$4.34

9

.BOOT, AXLE

59312-36500

$5.07

10

.INSULATOR, AXLE

59313-36500

$5.99

11

BRACKET

69150-44B00

Unavailable

12

BLEEDER

59121-18410

$8.73

13

CAP, BLEEDER This part replaces 59122-18410.

55156-66310

$5.17

14

BOLT (8X22)

09103-08259

$4.50
