Suzuki DR350SET (1996) RIGHT HANDLE LEVER (MODEL L/M) Diagram

#

Description
Price

1

GRIP, THROTTLE

57110-14D00

$31.85

2

CASE ASSY, THROTTLE | Includes Item(s) 3 - 6 This part replaces 57100-28B00.

57100-13610

$56.04

3

PIECE, GUIDE

57122-13600

Unavailable

4

COVER

57129-13601

$11.95

5

SCREW This part replaces 02132-04105.

02122-0410A

$1.49

6

SCREW

02112-05164

$2.63

7

LEVER, BRAKE

57421-03D00

$15.47

8

SCREW

57431-05D00

$13.20

9

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

10

BOLT, ADJUST

57431-14511

$5.80

11

NUT This part replaces 08310-12055.

08310-0005A

$1.84

12

SPRING, RETURN

57318-14502

$4.48

13

SWITCH ASSY,FR BRAKE | Includes Item(s) 14 This part replaces 57460-17C00.

57460-14J02

$38.46

14

SCREW

57465-17C00

$2.19

15

COVER, KNUCKLE RH (BLUE)

57341-05D00-0NF

$40.25

16

SCREW

09125-05042

$1.96

17

WASHER (5.5X16X1.2) This part replaces 09160-05017.

09160-05043

$2.30

18

.WASHER (6.5X16X1.6) This part replaces 09160-06042.

09160-06130

$1.91

19

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

20

REFER TO FIG.38A(G- 8) FOR

SPECIAL NOTE

Unavailable
