Suzuki DR250 (1985) RIGHT HANDLE SWITCH Diagram

#

Description

Price

1

GRIP,THROTTLE This part replaces 57110-37200.

57110-37201

$26.30

2

CASE ASSY, THROTTLE

57100-37230

Unavailable

3

SCREW This part replaces 02112-05208.

02112-05207

$1.97

4

LEVER

57421-13A10

$15.73

5

SCREW This part replaces 57431-13010.

09139-06114

$7.95

6

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

7

ADJUSTER

57443-13A00

$10.55

8

ROD, PUSH

57444-13A00

$6.09

9

CLAMP (L:120)

09407-12402

$3.04
