Description

Price

1

GRIP, THROTTLE

57110-14D00

$31.85

2

CASE ASSY, THROTTLE

57100-13610

$56.04

3

LEVER, BRAKE

57421-03D00

$15.47

4

BOLT, BRAKE LEVER

57431-14500

$6.28

5

NUT

08319-2106A

$1.91

6

BOLT, ADJUST

57431-14511

$5.80

7

NUT

08310-0005A

$1.84

8

SPRING, RETURN

57318-14502

$4.48

9

SWITCH ASSY,FR BRAKE This part replaces 57460-14J01.

57460-14J02

$38.46

10

SCREW

57465-17C00

$2.19

11

CLAMP (L:120)

09407-12402

$3.04

12

GRIP LH

57211-27C00

$12.28

13

LEVER ASSY,CLUT This part replaces 57500-44AF0.

57500-44AF1

$65.70

14

LEVER, CLUTCH

57621-44AF0

$21.12

15

..BOLT,LEVER PIVOT

57431-21D11

$9.76

16

NUT

08319-2106B

$2.32

17

.ADJUSTER,WIRE This part replaces 57441-08C00.

57441-08C01

$11.64

18

NUT, LOCK

57442-44AF0

Unavailable

19

BOLT

01547-06207

$2.01

20

SWITCH ASSY, CLUTCH

57560-44AF0
