Suzuki DR100 (1987) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

CASE ASSY, THROTTLE

57100-37400

$94.55

2

SCREW This part replaces 02112-05208.

02112-05207

$1.97

3

GRIP,THROTTLE This part replaces 57110-37200.

57110-37201

$26.30

4

LEVER ASSY, BRAKE | MODEL F/G/H/J/K This part replaces 57300-05200.

57300-05210

Unavailable

4

LEVER ASSY, BRAKE | MODEL L

57300-05220

Unavailable

5

LEVER, BRAKE (BLACK) | MODEL F/G/H/J/K

57420-26400

Unavailable

5

LEVER, BRAKE | MODEL L This part replaces 57420-05220.

57420-26500

$29.23

6

BOLT | MODEL F/G/H/J/K This part replaces 57431-11011.

57431-11013

$6.31

6

BOLT, LEVER | MODEL L

57431-11013

$6.31

7

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

8

ADJUSTER, CABLE

57441-26010

$4.48

9

NUT

57442-11010

$2.79

10

SCREW This part replaces 02112-06208.

02112-06207

$1.78

11

COVER, CLUTCH LEVER This part replaces 57341-40001.

57341-40003

$5.56

12

BAND

09407-12402

$3.04
